COMBO TAPS COMBO TAPS

TCE-S/TCF-S/TCE-C/TCF-C SERIES TCG-S/TCH-S/TCG-C/TCH-C SERIES

SPIRAL POINT TAPS for Stainless Steels SPIRAL POINT TAPS for Stainless Steels

Thread Depth / Thread Depth /
Hole Type Hole Type
3.0×D 3.0×D

VA Super HSS-EX UNC USCTI 4P Steam TiCN VA Super HSS-EX M/MF USCTI 4P Steam TiCN
302A
Oxide
Oxide
UNF
HSS
HSS
302A
Unit : Inch Unit : Inch
Overall Thread Shank Square Square EDP No. Overall Thread Shank Square Square EDP No.
SIZE & TPI Limit Length Length Diameter Size Length No. of Steam SIZE & TPI Limit Length Length Diameter Size Length No. of Steam
Flute
Flute
L Lt D K kl Oxide TiCN L Lt D K kl Oxide TiCN
9/16 - 12 UNC H3 3.59 .984 .429 .322 .500 3 TCF603S TCF603C M3 x 0.5 D3 1.94 .374 .141 .110 .188 3 TCG203S TCG203C
9/16 - 18 UNF H3 3.59 .984 .429 .322 .500 3 TCF623S TCF623C M3.5 x 0.6 D4 2.00 .413 .141 .110 .188 3 TCG224S TCG224C
5/8 - 11 UNC H3 3.81 1.083 .480 .360 .562 3 TCF643S TCF643C M4 x 0.7 D4 2.13 .453 .168 .131 .250 3 TCG244S TCG244C
5/8 - 11 UNC H5 3.81 1.083 .480 .360 .562 3 TCF645S TCF645C M5 x 0.8 D4 2.38 .531 .194 .152 .250 3 TCG284S TCG284C
5/8 - 18 UNF H5 3.81 1.083 .480 .360 .562 3 TCF665S TCF665C M6 x 1.0 D5 2.50 .591 .255 .191 .312 3 TCG315S TCG315C
3/4 - 10 UNC H3 4.25 1.201 .590 .442 .688 3 TCF703S TCF703C M7 x 1.0 D5 2.72 .669 .318 .238 .375 3 TCG345S TCG345C
3/4 - 10 UNC H5 4.25 1.201 .590 .442 .688 3 TCF705S TCF705C M8 x 1.25 D5 2.72 .669 .318 .238 .375 3 TCG365S TCG365C
7/8 - 9 UNC H4 4.69 1.339 .697 .523 .750 3 TCF744S TCF744C M8 x 1.0 D5 2.72 .669 .318 .238 .375 3 TCG375S TCG375C
7/8 - 9 UNC H6 4.69 1.339 .697 .523 .750 3 TCF746S TCF746C M10 x 1.5 D6 2.94 .748 .381 .286 .438 3 TCG426S TCG426C
7/8 - 14 UNF H6 4.69 1.339 .697 .523 .750 3 TCF766S TCF766C M10 x 1.25 D5 2.94 .748 .381 .286 .438 3 TCG435S TCG435C
1 - 8 UNC H4 5.13 1.496 .800 .600 .812 3 TCF784S TCF784C M12 x 1.75 D6 3.38 .984 .367 .275 .438 3 TCG506S TCG506C
1 - 8 UNC H6 5.13 1.496 .800 .600 .812 3 TCF786S TCF786C M12 x 1.25 D5 3.38 .984 .367 .275 .438 3 TCG525S TCG525C
1 - 12 UNF H6 5.13 1.496 .800 .600 .812 3 TCF806S TCF806C M14 x 2.0 D7 3.59 .984 .429 .322 .500 3 TCH547S TCH547C
M14 x 1.5 D6 3.59 .984 .429 .322 .500 3 TCH556S TCH556C
▶Super HSS(#5~1/2) and HSS-EX(9/16~1")
M16 x 2.0 D7 3.81 1.083 .480 .360 .562 3 TCH607S TCH607C
M16 x 1.5 D6 3.81 1.083 .480 .360 .562 3 TCH616S TCH616C
M18 x 2.5 D7 4.03 1.083 .542 .406 .625 3 TCH657S TCH657C
M18 x 1.5 D6 4.03 1.083 .542 .406 .625 3 TCH676S TCH676C
▶Super HSS(M3~M12) and HSS-EX(M14~M18)

◎ : Excellent ○: Good ◎ : Excellent ○: Good
P M K P M K
Low carbon steels/ Medium to high Steel castings & forgings / Alloyed tool steels/ Free machining Heat-and corrosionresistant Stainless steel castings / Grey Low carbon steels/ Medium to high Steel castings & forgings / Alloyed tool steels/ Free machining Heat-and corrosionresistant Stainless steel castings / Grey
Free machining carbon steels/ Heat-treatable alloy steels Mold steels stainless steels stainless steels / Precipitation hardening cast iron Free machining carbon steels/ Heat-treatable alloy steels Mold steels stainless steels stainless steels / Precipitation hardening cast iron
carbon steels Low alloyed steels Valve stainless steels stainless steels carbon steels Low alloyed steels Valve stainless steels stainless steels
~HRc15 ~HRc23 ~HRc24 (~HB250) ~HRc38 (~HB350) ~HRc23 ~HRc24 (~HB250) ~HRc38 (~HB350) ~HRc19 ~HRc15 ~HRc23 ~HRc24 (~HB250) ~HRc38 (~HB350) ~HRc23 ~HRc24 (~HB250) ~HRc38 (~HB350) ~HRc19
(~HB180) (~HB240) ~HRc38 (~HB350) ~HRc44 (~HB420) (~HB240) ~HRc38 (~HB350) ~HRc44 (~HB420) (~HB220) (~HB180) (~HB240) ~HRc38 (~HB350) ~HRc44 (~HB420) (~HB240) ~HRc38 (~HB350) ~HRc44 (~HB420) (~HB220)
○ ○ ◎ ○ ○ ◎
K N S K N S
Nodular cast iron / Pure and Free machining Pure Aluminum/ Aluminum 718 & 625 INCO / 718 Nodular cast iron / Pure and Free machining Pure Aluminum/ Aluminum 718 & 625 INCO / 718
Chilled cast iron / brass Bronze alloy Zinc Magnesium Waspaloy / Hastelloy / Inconel / Titanium Chilled cast iron / brass Bronze alloy Zinc Magnesium Waspaloy / Hastelloy / Inconel / Titanium
Meehanite iron / Ductile iron alloyed copper / Alloyed brass Aluminum alloy castings Invar / Monel / Incoloy A286 Meehanite iron / Ductile iron alloyed copper / Alloyed brass Aluminum alloy castings Invar / Monel / Incoloy A286
~HRc24 (~HB250) ~HRc24 (~HB250)
