SPIRAL SPIRAL
FLUTE TAPS BW / BX SERIES FLUTE TAPS C2/C3/C4/D9 SERIES

SPIRAL FLUTE TAPS MODIFIED BOTTOMING STYLE STANDARD TAPS : SPIRAL FLUTE TAPS BOTTOMING STYLE
for Aluminum Alloys or Die Cast Aluminum for General Purpose

Thread Depth / 2.5×D Thread Depth / 2.5×D
Hole Type Hole Type

USCTI USCTI

M
AI HSSE-V3 MF USCTI Bright Hardslick R50 ◇Call for Availability GS HSSE-V3 UNC USCTI 1.5P~2P Steam Bright TiN Hardslick R45
Oxide
302
302A
UNF
EDP No. Thread Per Inch EDP No.
SIZE Pitch Limit No. of Flute SIZE Limit No of Flute Steam
Bright Hardslick UNC UNF Bright TiN Hardslick
Oxide
M3 0.5 D3 2 BW203 BX203 #4 40 — H2 2 C2162 C3162 C4162 D9162
M4 0.7 D4 2 BW244 BX244 #5 40 — H2 3 C2202 C3202 C4202 D9202
M5 0.8 D5 2 BW285 BX285 #6 32 — H3 3 C2243 C3243 C4243 D9243
#8 32 — H3 3 C2283 C3283 C4283 D9283
M6 1.0 D5 2 BW315 BX315 #10 24 — H3 3 C2323 C3323 C4323 D9323
M8 1.25 D5 2 BW365 BX365 #10 — 32 H3 3 C2343 C3343 C4343 D9343
M10 1.50 D6 2 BW426 BX426 1/4 20 — H3 3 C2403 C3403 C4403 D9403
M10 1.25 D5 2 BW435 BX435 1/4 20 — H5 3 C2405 C3405 C4405 D9405
1/4
—
M12 1.75 D6 2 BW506 ◇ BX506 5/16 18 28 H3 3 C2423 C3423 C4423 D9423
H3
—
D9443
C4443
C3443
C2443
3
M12 1.50 D5 2 BW515 ◇ BX515 5/16 18 — H5 3 C2445 C3445 C4445 D9445
M12 1.25 D5 2 BW525 ◇ BX525 5/16 — 24 H3 3 C2463 C3463 C4463 D9463
3/8 16 — H3 3 C2483 C3483 C4483 D9483
▶DIN Length available: Bright Finish F1 Series & Hardslick coated F3 Series
▶Refer to technical data on page 520~554. 3/8 16 — H5 3 C2485 C3485 C4485 D9485
3/8 — 24 H3 3 C2503 C3503 C4503 D9503
7/16 14 — H3 3 C2523 C3523 C4523 D9523
7/16 14 — H5 3 C2525 C3525 C4525 D9525
7/16 — 20 H3 3 C2543 C3543 C4543 D9543
7/16 — 20 H5 3 C2545 C3545 C4545 D9545
1/2 13 — H3 3 C2563 C3563 C4563 D9563
1/2 13 — H5 3 C2565 C3565 C4565 D9565
1/2 — 20 H3 3 C2583 C3583 C4583 D9583
1/2 — 20 H5 3 C2585 C3585 C4585 D9585
9/16 12 — H5 3 C2605 C3605 C4605 D9605
9/16 — 18 H5 3 C2625 C3625 C4625 D9625
5/8 11 — H3 4 C2643 C3643 C4643 D9643
5/8 11 — H5 4 C2645 C3645 C4645 D9645
5/8 — 18 H3 4 C2663 C3663 C4663 D9663
3/4 10 — H3 4 C2703 C3703 C4703 D9703
3/4 10 — H5 4 C2705 C3705 C4705 D9705
3/4 — 16 H3 4 C2723 C3723 C4723 D9723
7/8 9 — H4 4 C2744 C3744 C4744 D9744
7/8 — 14 H6 4 C2766 C3766 C4766 D9766
1 8 — H4 4 C2784 C3784 C4784 D9784
◎ : Excellent ○: Good ▶Refer to technical data on page 520~554. ◎ : Excellent ○: Good
P M K P M K
Low carbon steels/ Medium to high Steel castings & forgings / Alloyed tool steels/ Free machining Heat-and corrosionresistant Stainless steel castings / Grey Low carbon steels/ Medium to high Steel castings & forgings / Alloyed tool steels/ Free machining Heat-and corrosionresistant Stainless steel castings / Grey
Free machining carbon steels/ Heat-treatable alloy steels Mold steels stainless steels stainless steels / Precipitation hardening cast iron Free machining carbon steels/ Heat-treatable alloy steels Mold steels stainless steels stainless steels / Precipitation hardening cast iron
carbon steels Low alloyed steels Valve stainless steels stainless steels carbon steels Low alloyed steels Valve stainless steels stainless steels
~HRc15 ~HRc23 ~HRc24 (~HB250) ~HRc38 (~HB350) ~HRc23 ~HRc24 (~HB250) ~HRc38 (~HB350) ~HRc19 ~HRc15 ~HRc23 ~HRc24 (~HB250) ~HRc38 (~HB350) ~HRc23 ~HRc24 (~HB250) ~HRc38 (~HB350) ~HRc19
(~HB180) (~HB240) ~HRc38 (~HB350) ~HRc44 (~HB420) (~HB240) ~HRc38 (~HB350) ~HRc44 (~HB420) (~HB220) (~HB180) (~HB240) ~HRc38 (~HB350) ~HRc44 (~HB420) (~HB240) ~HRc38 (~HB350) ~HRc44 (~HB420) (~HB220)
◎ ◎ ○ ○ ○
K N S K N S
Nodular cast iron / Pure and Free machining Pure Aluminum/ Aluminum 718 & 625 INCO / 718 Nodular cast iron / Pure and Free machining Pure Aluminum/ Aluminum 718 & 625 INCO / 718
Chilled cast iron / brass Bronze alloy Zinc Magnesium Waspaloy / Hastelloy / Inconel / Titanium Chilled cast iron / brass Bronze alloy Zinc Magnesium Waspaloy / Hastelloy / Inconel / Titanium
Meehanite iron / Ductile iron alloyed copper / Alloyed brass Aluminum alloy castings Invar / Monel / Incoloy A286 Meehanite iron / Ductile iron alloyed copper / Alloyed brass Aluminum alloy castings Invar / Monel / Incoloy A286
~HRc24 (~HB250) ~HRc24 (~HB250)
◎ ◎ ○ ○
