CARR LANE SIMPLEX HAMMERS

Blue thermoplastic inserts are soft and non- Gray thermoplastic inserts are medium soft
smudging. Applications include assembly and non-smudging. Applications include
operations, dent removal, woodworking, assembly operations, car-body work,
furniture assembly, window and door woodworking, furniture assembly, window
construction, joiner’s work, and floor tiling. and door construction, joiner’s work, floor
Hardness 60-70 Shore A. tiling, paving, and interior construction.
Hardness 85-95 Shore A.
HAMMER
SIZE HAMMER
PART NO. (FACE DIA) SIZE
CL-30-SPH-A 30mm (1.18) PART NO. (FACE DIA)
Type A Inserts CL-40-SPH-A 40mm (1.57) Type B Inserts CL-30-SPH-B 30mm (1.18)
Blue Thermoplastic CL-50-SPH-A 50mm (1.96) Grey Thermoplastic CL-40-SPH-B 40mm (1.57)
(Soft) CL-60-SPH-A 60mm (2.36) (Medium Soft) CL-50-SPH-B 50mm (1.96)
CL-60-SPH-B 60mm (2.36)

Black Rubber inserts are medium soft. White superplastic inserts (UHMW
Applications include assembly operations, polyethylene) are medium hard, durable,
dent removal, prefabricated housing impact resistant, acid and lye resistant,
construction, carpenter’s work, pav ing, grease and oil resistant, and ideal for striking
ma son ry work, concrete-form setup, scaffold sharp edges. Applications include assembly
construction, gardening, landscaping, and operations, automotive as sembly and repair
interior construction. Hardness 90-100 Shore work, repair and maintenance work, car body
A. work, sheet metal working, dent removal,
assembly of sharp-edged workpieces,
HAMMER paving, masonry work, scaffold construction,
SIZE gardening, and landscaping. Hardness 60-70
Type C Inserts PART NO. (FACE DIA) Shore D.
Black Rubber CL-30-SPH-C 30mm (1.18) Type D Inserts
(Medium Soft) CL-40-SPH-C 40mm (1.57) White Superplastic HAMMER
CL-50-SPH-C 50mm (1.96) (Medium Hard) SIZE
CL-60-SPH-C PART NO. (FACE DIA)
7 60mm (2.36)
CL-30-SPH-D 30mm (1.18)
CL-40-SPH-D 40mm (1.57)
CL-50-SPH-D 50mm (1.96)
Red plastic inserts (cellulose acetate) are hard, CL-60-SPH-D 60mm (2.36)
semi-transparent, and grease and oil resistant.
Applications include automotive assembly White nylon inserts are hard, grease and
and repair work, sheet metal working, dent oil resistant, highly elastic, and have superior
removal, concrete-form setup, and scaffold strike effectiveness. Applications include
construction. Hardness 65-75 Shore D.
assembly operations, metalworking, tooling,
automotive assembly and repair work, joining of
HAMMER
SIZE workpieces, sheet metal working, dent removal,
PART NO. (FACE DIA) mold construction, assembly of sharp-edged
CL-30-SPH-E 30mm (1.18) workpieces, and scaffold construction. Hardness
Type E Inserts CL-40-SPH-E 40mm (1.57) 68-78 Shore D.
Red Plastic CL-50-SPH-E 50mm (1.96) HAMMER
(Hard) CL-60-SPH-E 60mm (2.36) SIZE
Type F Inserts PART NO. (FACE DIA)
White Nylon CL-30-SPH-F 30mm (1.18)
(Hard)
Soft metal inserts are made of an aluminum- CL-40-SPH-F 40mm (1.57)
copper alloy which is hard and resistant to CL-50-SPH-F 50mm (1.96)
heat. Excellent alternative to old-fashioned CL-60-SPH-F 60mm (2.36)
lead hammers, to eliminate the risk of
lead contamination. Applications include Copper inserts are hard and provide
metalworking, tooling, automotive assembly maximum impact. Plastic socket provides
and repair work, straightening work, car body for secure mounting of the copper insert in
work, and mold construction. the hammer. Applications include machine
construction, automotive assembly and repair
HAMMER
SIZE work, repair and maintenance work, and
PART NO. (FACE DIA) vehicle service stations.
Type G Inserts CL-30-SPH-G 30mm (1.18)
Soft Metal CL-40-SPH-G 40mm (1.57) HAMMER
(Hard) SIZE
CL-50-SPH-G 50mm (1.96) PART NO. (FACE DIA)
CL-60-SPH-G 60mm (2.36) Type H Inserts
Copper CL-30-SPH-H 30mm (1.18)
(Hard) CL-40-SPH-H 40mm (1.57)
