NO-REBOUND DROP HAMMERS

HOUSING: STEEL ASSEMBLY CONTAINING STEEL PELLETS
INSERTS: NYLON, NATURAL WHITE COLOR, HARDNESS 68-78 SHORE D

No-Rebound Drop Hammers provide the impact of a normal
hammer even when access is restricted. No-Rebound Hammers
deliver full impact, about 50% greater than a standard hammer.
The housing is filled with special steel pellets that transfer
momentum to the impact point. Ideal for assembling machine
parts without damage. Speeds up work while reducing fatigue.
Allows better hammer control by absorbing the bounce.
Available in four sizes .
No-Rebound Drop Hammers have replaceable nylon inserts.
These nylon inserts are hard, grease and oil resistant, highly
elastic, and have superior strike effectiveness. Applications
include assembly operations, metalworking, tooling,
positioning of workpieces, automotive assembly and repair
work, joining of workpieces, sheet metal working, dent
No-Rebound Drop Hammers are filled removal, mold construction, and assembly of sharp-edged
with special steel pellets that transfer workpieces.
momentum to the impact point.
REPLACEMENT
FACE WEIGHT INSERT
PART NO. DIA (LBS) LENGTH (2 REQUIRED)
CL-3408-020-NRH 20mm (.78) 0.5 5.89 CL-3508-020-NRHI
CL-3408-030-NRH 30mm (1.18) 1.0 6.08 CL-3508-030-NRHI
CL-3408-040-NRH 40mm (1.57) 1.8 6.28 CL-3508-040-NRHI
CL-3408-050-NRH 50mm (1.96) 2.8 6.48 CL-3508-050-NRHI
SOFT-FACE PUNCHES
7
HOUSING: STEEL. INSERTS: NYLON, NATURAL WHITE COLOR, HARDNESS 68-78 SHORE D

Soft-Face Punches safely extend the reach of a hammer when
access is restricted. Transfers impact to difficult-to-reach
places. Available in two sizes.
Soft-Face Punches have replaceable nylon inserts. These
nylon inserts are hard, grease and oil resistant, highly elastic,
and have superior strike effectiveness. Applications include
assembly operations, metalworking, tooling, automotive
assembly and repair work, joining of workpieces, sheet
metal working, dent removal, and assembly of sharp-edged
workpieces.
REPLACEMENT
FACE WEIGHT INSERT
PART NO. DIA (LBS) LENGTH (2 REQUIRED)
CL-3408-010-SFP 10mm (.39) 0.2 6.59 CL-3508-010-NRHI
CL-3408-015-SFP 15mm (.59) 0.4 6.87 CL-3508-015-NRHI

NO-MAR HAMMERS

ALUMINUM ALLOY WITH STEEL CORE
Economical aluminum alloy hammer. Excellent alternative
STEEL CORE to old-fashioned lead hammers, to eliminate the risk of lead
contamination. One-piece cast construction with a steel core
for extra strength. Applications include metalworking, tooling,
automotive assembly and repair work, straightening work, car
body work, and mold construction. Available in two sizes.
HANDLE LENGTH
FACE TO CENTERLINE
PART NO. WEIGHT DIA OF FACE
CL-1-NMH 2 lb 1-1/2 10-1/2
CL-2-NMH 3.5 lb 2 11
