AIR FEED BUSHINGS

24000 SERIES (CONT.)

TAPER-LOK TAPER-LOK LOCK
A TIP ASSEMBLY SHANK ONLY COLLAR ONLY LINER LOCK LINER LOCK NUT LOCKSCREW SCREW LINER
ID B C STANDARD COOLANT STANDARD COOLANT STANDARD COOLANT PART NO. PART NO. PART NO. PART NO. PART NO. PART NO.
TYPE
TYPE
TYPE
TYPE
TYPE
TYPE
RANGE OD LENGTH PART NO. PART NO. PART NO. PART NO. PART NO. PART NO. p. 614 p. 615 p. 615 p. 613 p. 613 p. 613 INFO++
7/8 A-24405 A-14405 24405 14405
1 A-24406 A-14406 24406 14406
1-1/8 A-24408 A-14408 24408 14408
1-1/4 A-24410 A-14410 24410 14410
1-3/8 A-24411 A-14411 24411 14411
1-1/2 A-24413 A-14413 24413 14413
1-5/8 A-24414 A-14414 24414 14414
1-3/4 A-24415 A-14415 24415 14415
1-7/8 A-24416 A-14416 24416 14416
2 A-24418 A-14418 24418 14418
7/8
.3125-.6562 .8745-.8748 2-1/8 A-24419 A-14419 24419 14419
5/16-21/32 2-1/4 A-24420 A-14420 24420 14420 19950
8.00-16.50mm 2-3/8 A-24421 A-14421 24421 14421
2-1/2 A-24422 A-14422 24422 14422
2-3/4 A-24424 A-14424 24424 14424
3 A-24425 A-14425 24425 14425
3-1/4 A-24426 A-14426 24426 14426
3-1/2 A-24427 A-14427 24427 14427
3-3/4 A-24428 A-14428 24428 14428
4 A-24429 A-14429 24429 14429
5 A-24430 A-14430 24430 14430
6 A-24431 A-14431 24431 14431
1 A-24506 A-14506 24506 14506
1-1/8 A-24508 A-14508 24508 14508
1-1/4 A-24510 A-14510 24510 14510
1-3/8 A-24511 A-14511 24511 14511
1-1/2 A-24513 A-14513 24513 14513
1-5/8 A-24514 A-14514 24514 14514
1-3/4 A-24515 A-14515 24515 14515
1-7/8 A-24516 A-14516 24516 14516
1 2 A-24518 A-14518 24518 14518 CL-11-AFL 16532
.3125-.7812 .9998-.9995 2-1/8 A-24519 A-14519 24519 14519 24000 or
5/16-25/32 2-1/4 A-24520 A-14520 24520 14520 14000 CL-13-AFL 19951
8.00-19.50mm 2-3/8 A-24521 A-14521 24521 14521 or
2-1/2 A-24522 A-14522 24522 14522 CL-14-AFL
2-3/4 A-24524 A-14524 24524 14524
3 A-24525 A-14525 24525 14525
3-1/4 A-24526 A-14526 24526 14526
3-1/2 A-24527 A-14527 24527 14527
3-3/4 A-24528 A-14528 24528 14528
4 A-24529 A-14529 24529 14529
5 A-24530 A-14530 24530 14530
6 A-24531 A-14531 24531 14531
1 A-24606 A-14606 24606 14606
1-1/8 A-24608 A-14608 24608 14608
1-1/4 A-24610 A-14610 24610 14610
1-3/8 A-24611 A-14611 24611 14611
1-1/2 A-24613 A-14613 24613 14613
1-5/8 A-24614 A-14614 24614 14614
1-3/4 A-24615 A-14615 24615 14615
1-7/8 A-24616 A-14616 24616 14616
1-1/8 1-15/16 A-16505 A-14617 16505 14617 TLL-16525 A-16525
.3125-.9062 1.1248-1.1245 2 A-24618 A-14618 24618 14618 (Matches (Matches
5/16-29/32 2-1/8 A-24619 A-14619 24619 14619 A-24615 A-16505
8.00-23.00mm 2-1/4 A-24620 A-14620 24620 14620 Tip) Tip) 14446 19946
2-3/8 A-24621 A-14621 24621 14621
2-1/2 A-24622 A-14622 24622 14622
2-3/4 A-24624 A-14624 24624 14624 13
3 A-24625 A-14625 24625 14625
3-1/4 A-24626 A-14626 24626 14626
3-1/2 A-24627 A-14627 24627 14627
3-3/4 A-24628 A-14628 24628 14628
4 A-24629 A-14629 24629 14629
5 A-24630 A-14630 24630 14630
6 A-24631 A-14631 24631 14631
CONTINUED ON NEXT PAGE
