AIR FEED BUSHINGS

22000 SERIES

TAPER-LOK TAPER-LOK
TIP ASSEMBLY SHANK ONLY COLLAR ONLY LOCK
A LINER LOCK LINER LOCK NUT LOCKSCREW SCREW LINER
ID B C STANDARD COOLANT STANDARD COOLANT STANDARD COOLANT PART NO. PART NO. PART NO. PART NO. PART NO. PART NO.
TYPE TYPE TYPE TYPE TYPE TYPE INFO++
RANGE OD LENGTH PART NO. PART NO. PART NO. PART NO. PART NO. PART NO. p. 614 p. 615 p. 615 p. 613 p. 613 p. 613
3/8 A-22101 A-12101 22101 12101
1/2 A-22102 A-12102 22102 12102
5/8 A-22103 A-12103 22103 12103
3/4 A-22104 A-12104 22104 12104
7/8 A-22105 A-12105 22105 12105
1 A-22106 A-12106 22106 12106
1-1/8 A-22108 A-12108 22108 12108
1-1/4 A-22110 A-12110 22110 12110
1-3/8 A-22111 A-12111 22111 12111
1-1/2 A-22113 A-12113 22113 12113
1-5/8 A-22114 A-12114 22114 12114 19937
.1875-.2812 7/16 1-3/4 A-22115 A-12115 22115 12115
3/16-9/32 .4373-.4370 1-7/8 A-22116 A-12116 22116 12116
4.80-7.10mm 2 A-22118 A-12118 22118 12118
2-1/8 A-22119 A-12119 22119 12119
2-1/4 A-22120 A-12120 22120 12120
2-3/8 A-22121 A-12121 22121 12121
2-1/2 A-22122 A-12122 22122 12122
2-3/4 A-22124 A-12124 22124 12124
3 A-22125 A-12125 22125 12125
3-1/4 A-22126 A-12126 22126 12126
3-1/2 A-22127 A-12127 22127 12127
3-3/4 A-22128 A-12128 22128 12128
4 A-22129 A-12129 22129 12129
5 A-22130 A-12130 22130 12130
6 A-22131 A-12131 22131 12131
1/2 A-22202 A-12202 22202 12202
5/8 A-22203 A-12203 22203 12203
3/4 A-22204 A-12204 22204 12204
7/8 A-22205 A-12205 22205 12205
1 A-22206 A-12206 22206 12206 22000 CL-11-AFL 16532
1-1/8 A-22208 A-12208 22208 12208 12000 or
1-1/4 A-22210 A-12210 22210 12210 CL-13-AFL
1-3/8 A-22211 A-12211 22211 12211 or
1-1/2 A-22213 A-12213 22213 12213 CL-14-AFL
1-5/8 A-22214 A-12214 22214 12214
1-3/4 A-22215 A-12215 22215 12215 19938
1-7/8 A-22216 A-12216 22216 12216
.1875-.3438 2 A-22218 A-12218 22218 12218
3/16-11/32 1/2 2-1/8 A-22219 A-12219 22219 12219
4.80-8.70mm .4998-.4995 2-1/4 A-22220 A-12220 22220 12220
2-3/8 A-22221 A-12221 22221 12221
2-1/2 A-22222 A-12222 22222 12222
2-3/4 A-22224 A-12224 22224 12224
3 A-22225 A-12225 22225 12225
3-1/4 A-22226 A-12226 22226 12226
3-1/2 A-22227 A-12227 22227 12227
3-3/4 A-22228 A-12228 22228 12228
4 A-22229 A-12229 22229 12229
5 A-22230 A-12230 22230 12230
6 A-22231 A-12231 22231 12231
13
5/8 A-22303 A-12303 22303 12303
3/4 A-22304 A-12304 22304 12304
7/8 A-22305 A-12305 22305 12305 19939
1 A-22306 A-12306 22306 12306
1-1/8 A-22308 A-12308 22308 12308
.1875-.4062 9/16 1-1/4 A-22310 A-12310 22310 12310
3/16-13/32 .5623-.5620 1-3/8 A-22311 A-12311 22311 12311
4.80-10.20mm 1-1/2 A-22313 A-12313 22313 12313
1-5/8 A-22314 A-12314 22314 12314
1-3/4 A-22315 A-12315 22315 12315
1-7/8 A-22316 A-12316 22316 12316
CONTINUED ON NEXT PAGE.
