AIR FEED BUSHINGS

23000 SERIES

TAPER-LOK TAPER-LOK LOCK
A TIP ASSEMBLY SHANK ONLY COLLAR ONLY LINER LOCK LINER LOCK NUT LOCKSCREW SCREW LINER
ID B C STANDARD COOLANT STANDARD COOLANT STANDARD COOLANT PART NO. PART NO. PART NO. PART NO. PART NO. PART NO.
TYPE
TYPE
TYPE
TYPE
TYPE
TYPE
RANGE OD LENGTH PART NO. PART NO. PART NO. PART NO. PART NO. PART NO. p. 614 p. 615 p. 615 p. 613 p. 613 p. 613 INFO++
3/4 A-23104 A-13104 23104 13104
7/8 A-23105 A-13105 23105 13105
1 A-23106 A-13106 23106 13106
1-1/8 A-23108 A-13108 23108 13108
1-1/4 A-23110 A-13110 23110 13110
1-3/8 A-23111 A-13111 23111 13111
1-1/2 A-23113 A-13113 23113 13113
1-5/8 A-23114 A-13114 23114 13114
1-3/4 A-23115 A-13115 23115 13115
1-7/8 A-23116 A-13116 23116 13116
.2500-.5312 2 A-23118 A-13118 23118 13118
1/4-17/32 3/4 2-1/8 A-23119 A-13119 23119 13119
6.30-13.50mm .7498-.7495 2-1/4 A-23120 A-13120 23120 13120 19942
2-3/8 A-23121 A-13121 23121 13121
2-1/2 A-23122 A-13122 23122 13122
2-3/4 A-23124 A-13124 23124 13124
3 A-23125 A-13125 23125 13125
3-1/4 A-23126 A-13126 23126 13126
3-1/2 A-23127 A-13127 23127 13127
3-3/4 A-23128 A-13128 23128 13128
4 A-23129 A-13129 23129 13129 CL-11-AFL
5 A-23130 A-13130 23130 13130 or
6 A-23131 A-13131 23131 13131 23000 16532
3/4 A-23204 A-13204 23204 13204 13000 CL-13-AFL
or
7/8 A-23205 A-13205 23205 13205 CL-14-AFL
1 A-23206 A-13206 23206 13206
1-1/8 A-23208 A-13208 23208 13208
1-1/4 A-23210 A-13210 23210 13210
1-3/8 A-23211 A-13211 23211 13211
1-1/2 A-23213 A-13213 23213 13213
1-5/8 A-23214 A-13214 23214 13214
1-3/4 A-23215 A-13215 23215 13215
.2500-.5938 13/16 1-7/8 A-23216 A-13216 23216 13216
1/4-19/32 .8123-.8120 2 A-23218 A-13218 23218 13218
6.30-15.00mm 2-1/8 A-23219 A-13219 23219 13219 19943
2-1/4 A-23220 A-13220 23220 13220
2-3/8 A-23221 A-13221 23221 13221
2-1/2 A-23222 A-13222 23222 13222
2-3/4 A-23224 A-13224 23224 13224
3 A-23225 A-13225 23225 13225
3-1/4 A-23226 A-13226 23226 13226
3-1/2 A-23227 A-13227 23227 13227
3-3/4 A-23228 A-13228 23228 13228
4 A-23229 A-13229 23229 13229
5 A-23230 A-13230 23230 13230
6 A-23231 A-13231 23231 13231
CONTINUED ON NEXT PAGE
