I N DUS T R I A L A U T O M A TI O N & P R O C E S S C O NTRO L C A B L E S 42

®
Industrial Data Solutions — Industrial Twinax
®
Blue Hose Cables

Blue Hose Industrial Twinax

Nominal OD Operating Additional Features/
Part No. Voltage
Inch mm Temperature (°C) Ratings

20 AWG Stranded (7 x 28) TC Conductors • Polyethylene Insulation • Overall Beldfoil ® + 55% TC Braid Shielding • Blue Sunlight-Resistant PVC Jacket
NEC: CM CL2 • CEC: CM
9463 300V .238 6.05 -40 to +80 UL AWM 2464
MSHA Approved*
20 AWG Stranded (42 x 36) TC Conductors • Polyethylene Insulation • Overall Beldfoil + 85% TC Braid Shielding • Blue Sunlight-Resistant PVC Jacket
High Flex
NEC: CM CL2 • CEC: CM
9463F 300V .154 3.91 -40 to +80
UL AWM 2464
MSHA Approved*
20 AWG Stranded (7 x 28) TC Conductors • Polyethylene Insulation • Overall Beldfoil + 55% TC Braid Shielding • Blue Sunlight-Resistant LDPE Jacket
Aluminum Armored
129463 .563 14.30 -40 to +60 NEC: CM CL2 • CEC: CM,
HLBCD
Steel Armored
300V
139463 .563 14.30 -40 to +60 NEC: CM CL2 • CEC: CM,
HLBCD
Corrugated Armored
189463 .500 12.70 -20 to +60
UL PLTC
20 AWG Stranded (7 x 28) TC Conductors • Low-Density Polyethylene Insulation • Overall Beldfoil + 55% TC Braid Shielding • Polyethylene Jacket
Continuously Flooded
9463DB 300V .154 3.91 -55 to +80
Direct Burial
Stranded (7 x 28) TC Conductors • FEP Insulation • Overall Beldfoil + 55% TC Braid Shielding • Blue Sunlight-Resistant FEP Jacket
Plenum
89463 300V .151 3.83 -70 to +200 NEC: CMP CL2P • CEC:
CMP FT6
Conductor Color Codes: Blue, Clear.

*Pennsylvania Department of Environmental Resources and United States Mine Safety and Health Administration Certification
TC = Tinned Copper • FEP = Fluorinated Ethylene Propylene • LDPE = Low-Density Polyethylene • PVC = Polyvinyl Chloride
