Page 129 - 2017 Product Guide
P. 129
HEATED TOWEL RAILS | THERMORAIL
Technical Data
12 Volt Range
CODE DESCRIPTION BARS WIDTH HEIGHT DEPTH OUTPUT WIRING PAGE
MM (MM) (MM) WATTS OPTION NO
DSS4 Straight/Square, #304 Polished Stainless Steel 1 Bar 450 40 100 17 C, R 81
DSS6 Straight/Square, #304 Polished Stainless Steel 1 Bar 632 40 100 23 C, R 81
DSS8 Straight/Square, #304 Polished Stainless Steel 1 Bar 832 40 100 30 C, R 81
DSS6B Straight/Square, Black Powder Coated Finish 1 Bar 632 40 100 23 C, R 81
DSS6BR Straight/Square, Brushed Stainless Steel 1 Bar 632 40 100 23 C, R 81
DSS6W Straight/Square, White Powder Coated Finish 1 Bar 632 40 100 23 C, R 81
DSR6 Straight/Round, #304 Polished Stainless Steel 1 Bar 632 32 100 18 C, R 82
DSR6B Straight/Round, Black Powder Coated Finish 1 Bar 632 32 100 18 C, R 82
DSC6 Square/Curved Corners, #304 Polished Stainless Steel 1 Bar 640 40 100 23 C, R 82
DCR7 Curved/Round, #304 Polished Stainless Steel 1 Bar 700 32 100 15 C, R 82
DCF7 Curved/Flat, #304 Polished Stainless Steel 1 Bar 700 40 100 21 C, R 82
Straight/Round, Single Ended, #304 Polished Stainless
SER4 1 Bar 400 32 100 12 C 85
Steel
Straight/Round, Single Ended, #304 Polished Stainless
SER6 1 Bar 600 32 100 17 C 85
Steel
Straight/Square, Single Ended, #304 Polished
SES6 1 Bar 600 30 100 17 C 85
Stainless Steel
Straight/Round, Vertical Bar, #304 Polished Stainless
VS900H 1 Bar 142 900 100 30 C 86
Steel
VS900HB Straight/Round, Vertical Bar, Matt Black Coated Finish 1 Bar 142 900 100 30 C 87
Ladder Range
CODE DESCRIPTION BARS WIDTH (MM) HEIGHT (MM) DEPTH (MM) OUTPUT WIRING PAGE
(WATTS) OPTION NO
SR4412 Straight/Round, 12V, #304 Polished Stainless Steel 7 Bar 600 800 122 90 C, R, L 86
SS4412 Straight/Square, 12V, #304 Polished Stainless Steel 7 Bar 600 800 120 90 C, R, L 86
SR17M Straight/Round, #304 Polished Stainless Steel 8 Bar 400 1120 122 65 M 89
SR23M Straight/Round, #304 Polished Stainless Steel 8 Bar 530 700 122 76 M 89
SR27M Straight/Round, #304 Polished Stainless Steel 8 Bar 530 1120 122 80 M 89
SR33M Straight/Round, #304 Polished Stainless Steel 8 Bar 750 700 122 104 M 90
SR44M Straight/Round, #304 Polished Stainless Steel 7 Bar 600 800 122 80 M 90
SR69M Straight/Round, #304 Polished Stainless Steel 10 Bar 700 1200 122 128 M 90
SR93M Straight/Round, #304 Polished Stainless Steel 7 Bar 900 750 122 100 M 91
SR99M Straight/Round, #304 Polished Stainless Steel 14 Bar 1000 1500 122 244 M 91
Straight/Round, With Switch #304 Polished Stainless
SR44SM 7 Bar 600 800 122 90 M 91
Steel
CR40M Curved/Round, #304 Polished Stainless Steel 4 Bar 600 420 150 45 M 92
CR44M Curved/Round, #304 Polished Stainless Steel 7 Bar 600 800 150 80 M 92
CR27M Curved/Round, #304 Polished Stainless Steel 8 Bar 530 1120 150 82 M 92
CR23M Curved/Round, #304 Polished Stainless Steel 8 Bar 530 700 150 78 M 93
CR69M Curved/Round, #304 Polished Stainless Steel 12 Bar 700 1400 150 153 M 93
SS19M Straight/Square, #304 Polished Stainless Steel 10 Bar 450 1200 120 89 M 94
SS40M Straight/Square, #304 Polished Stainless Steel 4 Bar 600 420 120 47 M 94
SS44M Straight/Square, #304 Polished Stainless Steel 7 Bar 600 800 120 83 M 94
Wiring Option Key:
M = Multiflex (Concealed, Exposed, Left or Right, Top or Bottom) C = Concealed E = Exposed L = Left hand R = Right hand
FREE DELIVERY ON ALL ORDERS OVER $250.00 RRP E&OE ©THERMOGROUP 129
