Page 131 - 2017 Product Guide

HEATED TOWEL RAILS | THERMORAIL

Technical Data

Non Heated Range
CODE DESCRIPTION BARS WIDTH HEIGHT DEPTH PAGE
(MM) (MM) (MM) NO
USR54 Straight/Round, #304 Polished Stainless Steel 5 Bar 630 800 122 110
USS56 Straight/Square, #304 Polished Stainless Steel 5 Bar 650 1000 120 110
USF75 Straight/Flat, #304 Polished Stainless Steel 4 Bar 750 980 100 110
USSS45 Straight/Square/S Shape, #201 Polished Stainless Steel 5 Bar 600 900 100 111
USS49 Straight/Round, #201 Polished Stainless Steel 5 Bar 460 925 95 111
USS69 Straight/Round, #201 Polished Stainless Steel 5 Bar 610 925 95 111
USL44 Straight/Round, #201 Polished Stainless Steel 7 Bar 600 800 205 112
USS4 Straight/Square, #304 Polished Stainless Steel 1 Bar 450 40 100 113
USS6 Straight/Square, #304 Polished Stainless Steel 1 Bar 632 40 100 113
USS8 Straight/Square, #304 Polished Stainless Steel 1 Bar 832 40 100 113
USR6 Straight/Round, #304 Polished Stainless Steel 1 Bar 632 32 100 112
UCR7 Curved/Round, #304 Polished Stainless Steel 1 Bar 700 32 100 112
UCF7 Curved/Flat, #304 Polished Stainless Steel 1 Bar 700 40 100 112
USS6B Straight/Square, Black Powder Coated Finish 1 Bar 632 40 100 113
USS6BR Straight/Square, Brushed Stainless Steel 1 Bar 632 40 100 113
USS6W Straight/Square, White Powder Coated Finish 1 Bar 632 40 100 113
USR6B Straight/Round, Black Powder Coated Finish 1 Bar 632 32 100 112
UFS47 Straight/Flat, Free Standing, #201 Polished Stainless Steel 2 Bar 600 1000 220 104
Hydronic Range

CODE DESCRIPTION BARS WIDTH HEIGHT DEPTH PAGE NO
(MM) (MM) (MM)
HSRC44 Straight/Round, Chrome Plated Steel 4+4+5 Bar 600 800 79-98 116
HSRC48 Straight/Round, Chrome Plated Steel 3+5+5+8 Bar 600 1150 79-98 116
HSFC44 Straight/Flat Bar, Chrome Plated Steel 4+7 Bar 600 800 64-84 116
HSFC48 Straight/Flat Bar, Chrome Plated Steel 3+5+8 Bar 600 1200 64-84 117
Jeeves Range

CODE DESCRIPTION BARS WIDTH HEIGHT DEPTH ELEMENT WIRING PAGE
(MM) (MM) (MM) (W) OPTION NO
P62SPR Straight/Round, #304 Polished Stainless Steel 12 Bar 620 870 118 150 C, L, R 124
P62SBR Straight/Round, #304 Brushed Stainless Steel 12 Bar 620 870 118 150 C, L, R 124
P62SBKR Straight/Round, Satin Black Finish 12 Bar 620 870 118 175 C, L, R 124
K10SPR Straight/Round, #304 Polished Stainless Steel 10 Bar 1000 690 118 200 C, L, R 125
M62SPR Straight/Round with Shelf, #304 Polished Stainless Steel 7 Bar 620 555 326 120 C, L, R 125
W11SR Straight/Round/Swivel, #304 Polished Stainless Steel 6 Bar 520 1100 118 90 C, L, R 125
D62SPR Straight/Round, #304 Polished Stainless Steel 20 Bar 620 1340 118 250 C, L, R 126
D62SBR Straight/Round, #304 Brushed Stainless Steel 20 Bar 620 1340 118 250 C, L, R 126
L52SPR Straight/Round, #304 Polished Stainless Steel 5 Bar 520 1890 150 120 C, L, R 126
L52SBKR Straight/Round, Satin Black Finish 5 Bar 520 1890 150 200 C, L, R 127
T52SPR Straight/Round, #304 Polished Stainless Steel 5 Bar 520 930 118 90 C, L, R 127
T52SBKR Straight/Round, Satin Black Finish 5 Bar 520 930 118 135 C, L, R 127

Wiring Option Key:
M = Multiflex (Concealed, Exposed, Left or Right) C = Concealed E = Exposed L = Left hand R = Right hand

FREE DELIVERY ON ALL ORDERS OVER $250.00 RRP E&OE ©THERMOGROUP 131
