Page 130 - 2017 Product Guide

HEATED TOWEL RAILS | THERMORAIL

Technical Data

Ladder Range (Continued)
CODE DESCRIPTION BARS WIDTH HEIGHT DEPTH OUTPUT WIRING PAGE
(MM) (MM) (MM) (WATTS) OPTION NO
SS81M Straight/Square, #304 Polished Stainless Steel 4 Bar 800 440 120 61 M 95
SS88M Straight/Square, #304 Polished Stainless Steel 10 Bar 800 1160 120 153 M 95
SRS54M Straight/Round/Square, #304 Polished Stainless Steel 8 Bar 650 800 128 105 M 95
BS24M Straight/Round, #201 Polished Stainless Steel 3 Bar 550 450 122 33 M 96
BC44M Curved/Round, #201 Polished Stainless Steel 7 Bar 600 800 150 80 M 96
BS44M Straight/Round, #201 Polished Stainless Steel 7 Bar 600 800 122 80 M 97
BS46M Straight/Round, #201 Polished Stainless Steel 9 Bar 600 1080 122 103 M 97
BS28M Straight/Square, #201 Polished Stainless Steel 6 Bar 500 800 120 81 M 97
SFS44M Square/Flat, #304 Polished Stainless Steel 6 Bar 600 800 115 90 M 98
SFS69M Square/Flat, #304 Polished Stainless Steel 9 Bar 700 1200 115 160 M 98
SB34M Straight/Round with Ball Detail, #304 Polished Stainless Steel 5 Bar 560 850 140 60 M 98
SB79M Straight/Round with Ball Detail, #304 Polished Stainless Steel 7 Bar 680 1200 140 100 M 99
RSH38 Straight/Round Vertical Curve + Shelf, #304 Polished Stainless Steel 6 Bar 580 1190 225 75 C, R 99
SH44M Straight/Round + Shelf, #304 Polished Stainless Steel 7 Bar 600 800 250 87 M 99
RSL24R Straight/Round with Integrated Leg, #304 Polished Stainless Steel 8 Bar 500 800 110 75 C, R 100
RSL79R Straight/Round with Integrated Leg, #304 Polished Stainless Steel 10 Bar 780 1250 110 142 C, R 100
SO44 Straight/Oval/Round, #304 Polished Stainless Steel 6 Bar 600 800 125 68 C, R 100
SBR44M Straight/Round Box Shape, #304 Polished Stainless Steel 6 Bar 600 800 122 68 M 101
SF389 Straight/Square, 3 Piece #304 Polished Stainless Steel 6 Bar 850 740 110 165 C 101
SF389B Straight/Square, 3 Piece Matt Black Finish 6 Bar 850 740 110 165 C 101
FS55E Straight/Square, Free Standing, #201 Polished Stainless Steel 8 Bar 590 900 355 119 E 104
FS66E Straight/Round, Free Standing, #201 Polished Stainless Steel 8 Bar 600 1080 300 100 E 104
UFS47 Straight/Flat, Free Standing - Non Heated, #201 Polished St. Steel 2 Bar 600 1000 220 N/A N/A 104
SV24 Straight/Round Swivel #304 Polished Stainless Steel 4 Bar 600 540 99 48 C, E 105
SV43 Straight/Round Swivel #304 Polished Stainless Steel 6 Bar 675 740 99 77 C, E 105
SV35 Straight/Square Swivel, #304 Polished Stainless Steel 4 Bar 600 540 99 48 C,E 105
FC70S Straight/Square/Floor to Ceiling, #201 Polished Stainless Steel 16 Bar 700 2400-3000 40 230 C 106
FC70R Straight/Round, Floor to Ceiling, #201 Polished Stainless Steel 16 Bar 700 2400-3000 50 230 C 106
FC70B Straight/Round, Floor to Ceiling, Black Powder Coated Finish 16 Bar 700 2400-3000 50 230 C 106
SR44MB Straight/Round, Black Powder Coated Finish 7 Bar 600 800 122 120 M 107
BS48MB Straight/Square, Black Powder Coated Finish 6 Bar 600 800 120 100 M 107
BS44MW Straight/Round, White Powder Coated Finish 7 Bar 600 800 122 80 M 108
SRB27M Straight/Round, Brushed Stainless Steel Finish 8 Bar 530 1120 122 80 M 108
SRB69M Straight/Round, Brushed Stainless Steel Finish 10 Bar 700 1200 122 128 M 109
SR65GM Straight/Round with Ball Detail, Gold Finish 8 Bar 700 900 135 100 M 109
CR44GM Curved/Round, Gold Finish 7 Bar 600 800 155 90 M 109

Wiring Option Key:
M = Multiflex (Concealed, Exposed, Left or Right) C = Concealed E = Exposed L = Left hand R = Right hand
