INSULATION | ECONOBOARD INSULATION

Insulation Boards for Underfloor Heating

Using the correct Insulation Board is vital for an efficient electric underfloor heating system
as it minimises downward heat loss and reduces your running costs by as much as 50%

Uncoated boards for concrete Coated tile backer boards for Insulation boards for floating floor
substrates and under tile heating timber substrates and wetrooms build ups and timber flooring

5 Reasons to choose Uncoated 5 Reasons to choose Coated 5 Reasons to choose Rigid Boards
• Cost effective insulation solution • Cement coated & fibreglass reinforced • Designed for under laminate/timber
• 100% water resistant and rot proof • 100% water and rot proof • Provides thermal insulation & cushioning
• Made with extruded XPS foam • Excellent thermal insulation properties • Easy to cut, quick and simple to install
• Maximum insulation, minimal build up • Provides lateral stability for timber floors • Excellent thermal insulation properties
• Eliminates downward heat loss • Provides a perfect substrate for tiling • Minimal height build up

Econoboard Uncoated Insulation Boards are Econoboard Coated Insulation Boards are Econoboard Rigid Insulation Boards are
specially developed to provide economical reinforced with fibreglass mesh and a thin designed to provide thermal insulation and
thermal insulation for electric underfloor cement coating to provide strength and cushioning. Loose lay in a staggered brick
heating systems on concrete or screed floors. lateral stability to timber substrates. work pattern and tape together if required.

Fix to the substrate using a full bed of Fix to the substrate using wood screws To be left as a floating layer in a floating
flexible tile adhesive suitable for underfloor (6017) and Econoboard fixing washers floor build up below Thermofoil PRO.
heating systems. (6016) at 300mm centres around each Not suitable for under tile heating.
board.
Available in 6 & 10mm thick boards. Available in 5mm thick boards.
2
2
Board size 1.2 x 0.6m (0.72m ) Available in 6 & 10mm thick boards. Board size 1.2 x 0.5m (0.6m )
Board size 1.2 x 0.6m (0.72m )
2
For more details see page 58 - 59 For more details see page 56 - 57 For more details see page 60 - 61
Typical concrete floor build up Typical timber floor build up Typical floating floor build up

Tiled floor Tiled floor Timber floor
Econosoft (5422)
Flexible tile adhesive Flexible tile adhesive
Thermofoil PRO
Thermonet mat Thermonet mat
Rigid insulation
Econoboard Uncoated Econoboard Coated
Econoboard Coated
Flexible tile adhesive Timber substrate
Timber substrate
Concrete substrate
