INSULATION | RIGID INSULATION BOARD

Econoboard Rigid Insulation Board

Rigid insulation boards are designed to
provide thermal insulation and cushioning.
Loose lay in a staggered brick work pattern
and tape together if required.

To be left as a floating layer in a floating
floor build up below Thermofoil PRO.
Not suitable for under tile heating.

Available in 5mm thick boards.
Board size 1.2 x 0.5m.

5 Reasons to choose Rigid Boards
• Designed for under laminate/timber
• Provides thermal insulation & cushioning
• Easy to cut, quick and simple to install
• Excellent thermal insulation properties
• Minimal height build up

Insulation and cushioning for underlaminate heating mats
1
Rigid Insulation Board
2
STOCK DESCRIPTION R VALUE SIZE RRP EXCL RRP INCL
2
NO M k/W $ / PACK $ / PACK 3
5400 Rigid Insulation Board 5mm 0.215 pk10 (6m²) 90.00 99.00 4

5

6

1 Laminate or engineered floor finish
2 Econosoft Acoustic Barrier
3 Thermofoil™ PRO Underlaminate Foil
4 Rigid Insulation Board
5 Econoboard Coated Insulation Board
Every Thermofoil PRO installation should include a layer of Rigid Insulation Board (5400) under
6 Timber Substrate
the heating element. This layer acts as a 5mm cushion under the heating element to protect it
from any damage that could be caused by moving over the substrate. The insulation board also
acts as an insulation barrier, improving the efficiency and effectiveness of the underfloor heating.
Packaging information
• Available for purchase by the pack
See our dual Control Thermostat, • 1 board = 1.2 x 0.5m (0.6m )
2
2
Thermotouch 4.3dC on page 42 • 1 pack = 10 (6m )

FREE DELIVERY ON ALL ORDERS OVER $250.00 RRP E&OE ©THERMOGROUP 61
