Page 63 - 2017 Product Guide

INSULATION | ECONOSOFT ACOUSTIC BARRIER

Low Resistance Acoustic Barrier
Econosoft is a low heat resistance underlay
designed to protect underfloor heating
systems and provide excellent acoustic
properties. Econosoft also acts as a vapour
barrier to protect the floor finish. Roll size
15.0m x 1.0m

5 Reasons to choose Econosoft
• Super thin - only 1.2mm thick
• Low thermal resistance - TOG 0.14
• Impact sound reduction - 21dB
• Acts as an effective vapour barrier
• Self adhesive overlap installation

1
2

3
4

5
Low resistance Acoustic Barrier and abrasion layer
6
Econosoft Acoustic Barrier
STOCK DESCRIPTION ROLL SIZE UNIT RRP EXCL RRP INCL
NO M2 $ $
5422 Econosoft Acoustic Barrier 15 roll 308.18 339.00

1 Laminate or engineered floor finish
Without an acoustic barrier With an acoustic barrier 2 Econosoft Acoustic Barrier
3 Thermofoil™ PRO Underlaminate Foil
4 Rigid Insulation Board
5 Econoboard Coated Insulation Board
6 Timber Substrate

Econosoft Acoustic Barrier

Econosoft Acoustic Barrier (5422) should be
used with every Thermofoil PRO installation.
The Econosoft layer provides cushioning for
the heating cables and acts as an abrasion
Without an adequate acoustic insulation layer When an acoustic insulation layer is installed layer to protect the heating elements from
impact sound from foot traffic and other sources below the floor finish, impact sound is absorbed any wear that could be caused by movement
permeates through the building fabric causing and noise pollution is greatly reduced. in a floating floor build up.
noise pollution and disturbances.
Econosoft also has acoustic properties and the
This noise can create an unpleasant environment cushioning layer will reduce impact sound by
in domestic and commercial properties. as much as 21dB when used with a suitable
underlay such as Rigid Insulation Board.

FREE DELIVERY ON ALL ORDERS OVER $250.00 RRP E&OE ©THERMOGROUP 63
