SECTION 6.0 – INTERIOR WORKS FURNISHING AND OTHER FITTINGS SECTION 6.0 – INTERIOR WORKS FURNISHING AND OTHER FITTINGS

i. 18 mm thick post-formed moisture-resistant particleboard w) Hardware for all built-in furniture of post-formed moisture-resistant
laminated with 0.7 mm thick HPL complete with 2 mm thick ABS particleboard laminated with HPL with doors/drawers shall be designed
edging for all cabinet doors, drawer fronts, top and underside handle-free. The design must take into account for easy maintenance,
panels, and side panels. wear-resistant, and ergonometric purposes.

ii. 18 mm thick particleboard laminated with 0.7 mm thick HPL and x) Adequate numbers of ventilated built-in lockers shall be provided in all
2 mm thick ABS edging for the carcass, shelves of pigeon holes, the staff changing rooms and patients’ changing rooms, as required by
tall cabinets, and racks all around. the Government.

iii. 12 mm thick melamine board with 0.5 mm thick PVC edging for y) All clinical wet and sterile areas shall be provided with the approved
drawer sides and back. quality of stainless steel racks, worktops, and cabinets.

iv. 4 mm thick polyester for cabinet and wardrobe back panels and z) All stores, equipment rooms, and medical record rooms shall be
drawer base. provided with approved quality heavy-duty racking.

v. All cabinets’ width shall follow the modular dimension of 300 mm, aa) Metal compactor cabinets with steering wheels shall be provided at
450 mm, 600 mm, and 900 mm. Medical Record Room, Central Registration, or otherwise stated. The
track shall be embedded with the floor.
vi. All cabinets shall have adequate and durable support, depending
on the type of system used.
6.2.3 Loose Furniture
v) Hardware for all built-in furniture shall be as listed but not limited as
follows: The successful tenderer shall submit a detailed schedule of loose furniture
i. Drawer runner - side-mounted metal drawer with soft closing drawn up and submitted as part of the proposal, as shown in Appendix 8
mechanism and load-bearing capacity of 15 kg. The drawer must – Schedule of Loose Furniture.
be supported by powder-coated metal/steel structure or bracing.
a) All fit-outs and loose furniture shall be supplied and installed in all
ii. Hinges – stainless steel soft closing hinges with 105 to 110 relevant areas.
o
o
degree opening and zero cranking with adjustment for the
cabinet’s door panel. i. Office spaces shall be furnished with furniture and workstation to
the PD’s concurrence.
iii. Sliding rail - Drawer telescopic slides components are required.
ii. Head of department’s room, officer’s room and other required
iv. Shelf support – Aluminium with stainless steel studs. rooms shall be completely furnished and in compliance with the
latest EPU Guidelines and Pekeliling Perbendaharaan Malaysia
v. Hanger rod – 20 mm diameter chrome-plated steel tubular clothes WP 2.1 – Peraturan dan Had Harga Perabot/ Kelengkapan Bagi
hanger. Pejabat Anggota-Anggota Perkhidmatan Awam Persekutuan
(Termasuk Anggota Polis Diraja Malaysia).
vi. Cylinder lock – a minimum of 50% of total cabinets in every room
shall be lockable. iii. The successful tenderer shall provide documentation complete
with a list of indicative furniture design proposals with pictures,
vii. Flexible plastic cabinet door lips to avoid gaps between door catalogues, and specifications on the length, breadth, height, and
panel. materials used and the quantities of the items proposed for each
room.
viii. Furniture silicone rubber pad at all steel legs. iv. All loose furniture shall be read in conjunction with the Project
Brief and Government Requirements for Medical Equipment, Non-
ix. Glass at cabinet’s door shall be slot-in type. Medical Equipment, Loose Furniture, and Vehicles.
