PRODUCT SPOTLIGHT
Software Package for Waterjet Cutting
The efficiency and speed with which cutting tasks can be
executed is to a great extent determined by proper job
preparation.
Resato supplies the IGEMS CAD/ o Assigning the type and height of
CAM software package, specifically material
developed for waterjet cutting. o Fast and efficient manual nesting
The software package will be fully o Automatic generation of the CNC
installed on a customer’s PC, on which program
we will also install the software for o Sending the CNC program to the
sending/receiving of cutting programs cutting table
to/from the CNC controller. The CNC
controller has a cable connection to the • Import of files in DXF and DWG Options
PC. formats
• Determination of a material’s Nesting Module
Important features of the “machinability” through a single test Signmaker Module
standard IGEMS software cut Organizer Module
are: • The machinability determines: Data Exchange Module
• Quick and easy operation, including o Cutting speed Floating License
drawing capability
o Slowing and acceleration around
• Fast and logical workflow for: corners and tight curves School License
o Importing cutting jobs www.resato.com
New Chipbreaker Solution for High-Feed Milling in
Hardened Steel
Tungaloy is adding its latest chipbreaker innovation to the DoFeed family. The new MH
chipbreaker line is dedicated to machining ISO H workpiece materials.
DoFeed is a popular high feed mill enhance its robustness during tough o Chipping and fracture resistant,
line designed for 3D-profiling and hardened steel milling. Therefore, the MH chipbreaker is perfect for
contouring ISO H materials, such as premature insert failure due to chipping machining hardened steel
die steels and pre-hardened tool steel and fracture on the cutting edge is o AH8015 for hardened steel of 45
blocks commonly used in the die and significantly reduced. -55 HRc; AH8005 for 55 HRc and
mold industry. The new MH chipbreaker AH8015 and AH8005 are the standard above
is developed specifically for machining insert grades of this line, featuring
hardened steel of 50 HRc or above.
high aluminum content, multi-layered
A common issue in milling hardened AlTiN coating with a dedicated carbide 45
steel is unstable tool life due to substrate for excellent resistance to
unexpected chipping or fracture on the fracture and wear. AH8015 is designed
insert’s cutting edge. Incorporating a for hardened steel of 45–55 HRc, while
large wiper radius on the cutting edge, AH8005 is ideal for hardened steel of 55
MH chipbreaker enables a smooth HRc and above.
tool entry to the hardened workpiece, • At-a-glance: | Global MDA Journal | NOV-DEC 2017
reducing the risk of insert failures due
to the abrupt impact at tool entry. The o High density milling cutter for www.tungaloy.com
rake face angle is also optimized to ultimate efficiency
