P. 114
LED Lichtlinie slimlux 19 - RGB
LED Linear Lighting slimlux 19 - RGB
Lignes lumineuses LED slimlux 19 - RVB
IP 20
120° IP 64 ALU
IP 67
Lichtlinie für Aufbaumontage, Breite 18,4 mm, Höhe 19 mm
homogenes Leuchtbild
auf Maß konfektioniert, mit Endkappen, max. Länge 5 m
robuste Ausführung
weitere Ausführungen auf Anfrage
Line light for surface mounting, width 18.4 mm, height 19 mm
homogenous illumination pattern
max. 5 m
made to measure, with end caps, max. length 5 m
robust design
further versions upon request
18,4 mm
15 mm
ligne de lumière pour montage, largeur 18,4 mm, hauteur 19 mm
résultat d'éclairage homogène
fabriqué sur mesure, aux capuchons sur les extrémités, longueur maxi. 5 m
d'autres exécutions sur demande 13,4 mm 19,6 mm
Art.-No. Model IP Design
8 mm
Profi l ▪ Profile ▪ Profil
mit diff user Abdeckung
62190.20.XXX sl 19 d 20 ALU IP 20 with diff use cover Ø 5 mm
avec un recouvrement diff us
6 x 0,25 mm²
Versiegelt, mit diff user Abdeckung
62190.64.XXX sl 19 d 64 ALU IP 64 Sealed, with diff use cover
Scellé, avec un recouvrement diff us
mit diff usem Vollverguss 1 A
62190.67.XXX sl 19 d 67 ALU IP 67 with diff use full grouting 1
avec un scellement diff us intégral 1
Art.-No. CRI Watt
LED Band ▪ LED stripe ▪ Bande LED
XXXXX.XX.802.4979 RGB (WW), 2700 K 661 lm/m >80 24 V DC 15 W/m 83 mm 15/15 mm
XXXXX.XX.804.3696 RGB (NW), 4000 K 661 lm/m >80 24 V DC 15 W/m 83 mm 15/15 mm 21,5 mm
1 Durch den Verguss verändert sich der Wert der Lichtfarbe geringfügig
1
The grouting changes the lighting colour value slightly
1 Le scellement transparent change la valeur de la couleur de la lumière légèrement
22 mm
Art.-No. Anschluss + Endkappen ▪ Connection and end caps ▪ Connexion et capuchons Mit Montageclip
With mounting clip
Avec clip de montage
Anschluss und Endkappen ▪ Connection and end caps ▪ Connexion et capuchons
5 m Endkappen Kunststoff und Konfektionierung, off enes Kabel
62190A.50.45 5 m Plastic end caps and standard packing, open cable
5 m Embouts et assemblage en plastique, câble ouvert B
5 m Endkappen Metall und Konfektionierung, off enes Kabel
62190A.51.45 5 m Metal end caps and standard packing, open cable
5 m Capuchons sur les extrémités métal et fabrication spéciale, câble ouvert
5 m Endkappen Metall mit Befestigungsslaschen, off enes Kabel
62190A.52.45 5 m Metal end caps with fastening straps, open cable
5 m Embouts métalliques avec sangles de fi xation, câble ouvert
Zubehör ▪ accessories ▪ accessoires ► slimlux 19 RGB
LED Lichtlinien ▪ LED Linear Lighting ▪ Lignes lumineuses LED
Weiteres Zubehör Seite ▪ additional accessories page ▪ autre accessoires à la pâge ► 115 + 149
180°
114
