Page 455 - Deko-Light Light Impressions 2019-20
P. 455
COB 25 SOFT WW
stainless steel
dimensions L x Ø: 190 x 250 mm
power input: 29,10 W
energy efficiency class [EEI] spectrum A ++ to E
730421 silver coloured brushed WW 3000 K 1650 lm EEI: A
220-240 1
25 W COB LED Ra>80 35° 222 220 IP67
suitable outdoor mounting material from page 783
BASIC I WW
stainless steel
dimensions H x Ø: 65 x 45 mm
dimmable via optional controller
power input: 0,60 W
energy efficiency class [EEI] spectrum A ++ to E
730339 silver coloured | round WW 3000 K 15 lm EEI: A+
730340 silver coloured | square WW 3000 K 14 lm EEI: A+
CV 24 0,60 W SMD 1 Ra>80 60° IP67
LED 42 83
accessories
872041 power supply | 24V DC | 12 W | IP66
872618 power supply | 24V DC | 36 W | IP67
843022 RF single controller dimmable | 12 - 24V DC | max. 360 W
843336 DMX LED dimmer 2 dimmable | 12 - 24V DC
843010 DALI 4 channel PWM dimmer | 12 - 24V DC
suitable dimmers and controllers from page 692
suitable Weipu cable systems from page 772
454 OUTDOOR LAMPS | ground built-in lamps
