Page 456 - Deko-Light Light Impressions 2019-20
P. 456
ALZIRR
stainless steel
dimensions H x Ø: 82,50 x 55 mm
dimmable via optional controller
power input: 2,60 W
energy efficiency class [EEI] spectrum A ++ to E
730462 silver coloured WW 3000 K 150 lm EEI: A+
1
CV 24 2,60 W LED Ra>80 30° 48 97,25 IP67
accessories
872041 power supply | 24V DC | 12 W | IP66
872618 power supply | 24V DC | 36 W | IP67
843022 RF single controller dimmable | 12 - 24V DC | max. 360 W
843336 DMX LED dimmer 2 dimmable | 12 - 24V DC
843010 DALI 4 channel PWM dimmer | 12 - 24V DC
suitable dimmers and controllers from page 692
suitable Weipu cable systems from page 772
EASY ROUND III CWA
stainless steel
dimensions H x Ø: 80 x 55 mm
asymmetric
dimmable via optional controller
power input: 2,60 W
energy efficiency class [EEI] spectrum A ++ to E
131014 silver coloured CW 6000 K 125 lm EEI: A+
CV 24 2,60 W 1 Ra>70 45°/35° IP67
LED 48 97,25
accessories
872041 power supply | 24V DC | 12 W | IP66
872618 power supply | 24V DC | 36 W | IP67
843022 RF single controller dimmable | 12 - 24V DC | max. 360 W
843336 DMX LED dimmer 2 dimmable | 12 - 24V DC
843010 DALI 4 channel PWM dimmer | 12 - 24V DC
suitable dimmers and controllers from page 692
suitable Weipu cable systems from page 772
OUTDOOR LAMPS | ground built-in lamps 455
