Page 730 - Deko-Light Light Impressions 2019-20
P. 730
HEP POWER SUPPLY LAV60W24V1C
1 - 10V dimmable
872817 white 24V 60W 2,50A 280 x 30 x 27,5 mm
220-240 60 M M
CV
KAPEGO POWER SUPPLY | DESIGN IP
aluminium housing
short-circuit proof and overload protection
1 - 10V dimmable
872011 silver 12V 150W 223 x 70 x 40 mm
872012 silver 24V 150W 223 x 70 x 40 mm
110-240 150 M M
CV IP67
MEANWELL POWER SUPPLY HLG-SERIE
aluminium housing
1 - 10V dimmable
minimum load: 80%
maximum load: up to 100% of the power even in continuous operation
872019 silver 12V 39,9W 3,33A 171 x 61,5 x 36,8 mm
872021 silver 12V 60W 5,00A 195,6 x 61,5 x 38,8 mm
872023 silver 12V 120W 10,00A 220 x 68 x 38,8 mm
872020 silver 24V 40W 1,67A 171 x 61,5 x 36,8 mm
872022 silver 24V 81W 3,40A 195,6 x 61,5 x 38,8 mm
872024 silver 24V 120W 5,00A 220 x 68 x 38,8 mm
872043 silver 24V 320W 13,30A 352 x 90 x 43,8 mm
110-240 CV max 320 IP67 M M
POWER SUPPLY | DC | indoor and outdoor | constant voltage | 1 - 10V dimmable 729
