Page 731 - Deko-Light Light Impressions 2019-20
P. 731
BASIC INFORMATION ON THE USE OF DALI BALLASTS
DALI SINGLE DIMMER DALI BUS READY
DALI single dimmers cannot be integrated into existing These components can be integrated and controlled in
DALI networks. The control takes place via so-called single existing DALI BUS systems that comply with the IEC 62386
dimmers, which generate their own control signal. protocol.
KAPEGO POWER SUPPLY DALI DCV
DALI BUS ready according to protocol IEC 62386
supports touch dimmer function [Push]
soft dimming without flicker
843277 white 12V 40W 3,40A 122 x 78 x 32 mm
843278 white 24V 40W 1,70A 122 x 78 x 32 mm
110-240 40
CV
design example
MEANWELL POWER SUPPLY ELG-SERIES
aluminium housing
DALI BUS ready according to protocol IEC 62386
872066 silver 12V 60W 180 x 63 x 35,5 mm
872068 silver 12V 120W 219 x 63 x 35,5 mm
872070 silver 12V 192W 244 x 71 x 37,5 mm
872067 silver 24V 75W 180 x 63 x 35,5 mm
872069 silver 24V 120W 219 x 63 x 35,5 mm
872071 silver 24V 240W 219 x 63 x 35,5 mm
110-240 CV max 240 IP67
730 POWER SUPPLY | DC | indoor and outdoor | constant voltage | dimmable via DALI
