Page 481 - Deko-light Catalogue 2022
P. 481
LED PANEL ROUND III 20
aluminium diecast
dimensions H x Ø: 38 x 180 mm
dimmable via optinional power supply unit
565233 Traffic white RAL 9016 WW 3000 K 1980 lm 102,95 €
565234 Traffic white RAL 9016 NW 4000 K 1970 lm 102,95 €
108
CC 700 mA 28 20 W SMD LED Ra>80 100° 160 36
accessories
862198 power supply | 700 mA | 21-43V | 14,7-30,0 W 25,95 €
862207 power supply dimmable | 700 mA | 14,0-28,0V | 9,8-20,0 W 42,95 €
862191 power supply MULTI-CC DALI DALI1/2/Intelli-Push dimmable | 20-36V | 14,0-25,0 W 64,95 €
LED PANEL ROUND III 26
aluminium diecast
dimensions H x Ø: 38 x 230 mm
dimmable via optinional power supply unit
565235 Traffic white RAL 9016 WW 3000 K 2680 lm 123,95 €
565236 Traffic white RAL 9016 NW 4000 K 2690 lm 123,95 €
144
CC 700 mA 37 26 W SMD LED Ra>80 100° 200 36
accessories
862198 power supply | 700 mA | 21-43V | 14,7-30,0 W 25,95 €
862208 power supply dimmable | 700 mA | 28-56V | 19,6-40,0 W 49,95 €
862192 power supply MULTI-CC DALI1/2/Intelli-Push dimmable | 25-64V | 17,5-45,0 W 69,95 €
COMMERCIAL LIGHTS | built in ceiling lights 479
