Page 835 - Deko-light Catalogue 2022

3528-120-12V-2700K / 3000K / 4000K / 6500K-5M

8,33 mm 25 mm / 3 LED 120°

1,7 mm
r 20 mm
stripe length: 5 m max. total length to be operated: 5 m minimum bending radius

8 mm
feed-in: 1000 mm secondary feed-in: 1000 mm

840164 5 m roll 2700K [+/- 150K] 120 LED/m 7,0 W/m 81,43 lm/W 570 lm/m 89,95 €
840165 5 m roll 3000K [+/- 150K] 120 LED/m 6,5 W/m 85,38 lm/W 555 lm/m 89,95 €
840166 5 m roll 4000K [+/- 150K] 120 LED/m 7,0 W/m 95,71 lm/W 670 lm/m 89,95 €
840167 5 m roll 6500K [+/- 150K] 120 LED/m 7,0 W/m 90,00 lm/W 630 lm/m 89,95 €

- 15°C
CV 12 SMD Ra 90 1 CH IP20 + 50°C
3528

3528-120-12V-4000K-5M-NANO

1,4 mm
8,33 mm 25 mm / 3 LED 120°

r 20 mm
stripe length: 5 m max. total length to be operated: 5 m minimum bending radius

8 mm
feed-in: 1000 mm secondary feed-in: 1000 mm

840170 5 m roll 4000K [+/- 150K] 120 LED/m 7 W/m 94,29 lm/W 660 lm/m 119,95 €

- 15°C
CV 12 SMD Ra 90 1 CH IP33 + 50°C
3528
LED STRIPES | standard | 1CH | 12V | IP20/IP33 833
