Page 839 - Deko-light Catalogue 2022

3528-120-24V-2700K / 3000K-5M

1,5 mm
8,33 mm 50 mm / 6 LED 120°

r 20 mm
stripe length: 5 m max. total length to be operated: 5 m minimum bending radius

5 mm
feed-in: 1000 mm secondary feed-in: 1000 mm

840158 5 m roll 2700K [+/- 150K] 120 LED/m 8,5 W/m 80,00 lm/W 680 lm/m 79,95 €
840159 5 m roll 3000K [+/- 150K] 120 LED/m 10,5 W/m 69,52 lm/W 730 lm/m 79,95 €

- 15°C
CV 24 SMD Ra 90 1 CH IP20 + 50°C
3528

2835-120-24V-3000K-10M

1,5 mm
8,33 mm 50 mm / 6 LED 120°

r 20 mm
stripe length: 10 m max. total length to be operated: 10 m minimum bending radius

10 mm
feed-in: 1000 mm secondary feed-in: 1000 mm

840291 10 m roll 3000K [+/- 150K] 120 LED/m 9,5 W/m 74,21 lm/W 705 lm/m 399,95 €

- 15°C
CV 24 SMD Ra 90 1 CH IP20 + 50°C
2835
LED STRIPES | standard | 1CH | 24V | IP20 837
