Page 846 - Deko-light Catalogue 2022

2835-78-48V-3000K-15M / 3000K-50M / 4000K-15M / 4000K-50M-SILIKON

new

2,5 mm
12,82 mm 166,66 mm / 13 LED 120°

r 50 mm
stripe length: 15 / 50 m max. total length to be operated: 50 m minimum bending radius

10 mm
feed-in: 1000 mm secondary feed-in: 1000 mm

840317 15 m roll 3000K [+/- 150K] 78 LED/m 4 W/m 100,00 lm/W 400 lm/m 499,95 €
840338 50 m roll 3000K [+/- 150K] 78 LED/m 4 W/m 101,25 lm/W 405 lm/m 1599,95 €
840319 15 m roll 4000K [+/- 150K] 78 LED/m 4 W/m 113,75 lm/W 455 lm/m 499,95 €
840340 50 m roll 4000K [+/- 150K] 78 LED/m 4 W/m 113,75 lm/W 455 lm/m 1599,95 €

- 15°C
CV 48 SMD Ra 80 1 CH IP44 + 50°C
2835

1808-700-48V-3000K / 4000K-5M-SILIKON

new

4,0 mm 6,0 mm 1,4 mm
1,43 mm 20 mm / 14 LED 120°

r 50 mm
stripe length: 5 m max. total length to be operated: 5 m minimum bending radius

12 mm 14 mm 10 mm
feed-in: 1000 mm secondary feed-in: 1000 mm With the kind support of BEST Bellemann Elektro Service Team GmbH, Rauenberg-Malschenberg

840343 5 m roll 3000K [+/- 150K] 700 LED/m 21 W/m 80,00 lm/W 1680 lm/m 299,95 €
840345 5 m roll 4000K [+/- 150K] 700 LED/m 20 W/m 85,25 lm/W 1705 lm/m 299,95 €

- 15°C
CV 48 SMD Ra 90 1 CH IP65 + 50°C
1808
incl. accessories: 10x retaining bracket, 20x stainless steel screw, 2x endcap

844 LED STRIPES | standard | 1CH | 48V | IP44/IP65
