WHAT CAN QUASAR CONTROL? EASY AND QUICK INSTALLATION

By using the two modules [see pages 802-805] there are Due to the compact design and depending on the applica-
countless connection options for almost all types of common tion, the modules can often be installed almost »invisibly«
lights, illuminants and components. From conventional light directly in the junction box, in the lamp canopy or with the
bulbs, LED / retro-Fit lamps, LED lights with permanently power supply. The modules are already pre-configured for
installed electronic ballasts, power supplies with 0-10V / the most common applications, which means that the most
1-10V control input, 1-4 channel LED strips and all compatible important functions can be operated and tested using the
devices and consumers that can be switched or dimmed switch inputs after installation, even without using the
using 230V mains voltage. Quasar app. A multi-coloured signal LED inside the module
provides information about the operating status and any
faults at any time.

OPTIONAL OPERATING MODES CUSTOMIZE SWITCHING SIGNALS

Depending on the Quasar module used and the connected Many switching parameters such as the duty cycle,
one consumers can select the required operating mode dimming behaviour, soft start, switch-on and switch-off
quickly and easily. Switching, dimming, different modes for delays as well as the minimum and maximum brightness
1-4 channel LED strips and a special sensor mode enable can be adapted to the respectively connected lights or
previously unimagined control options and functions. consumers.

RANGE AND SECURITY FLEXIBLE USE AND OPERATION
By using the latest microprocessors and encrypted Multi- The modules can be used as individual, autonomously
Protocol-Mesh-Technology, the Quasar modules offer operating controllers or in combination with many others
maximum security and maximum range. Each module also controllers they work in networked operation. No central
serves as a repeater within the network and increases the control unit is required. Every controller can be operated
range accordingly. Any Quasar module can be used as a repe- by up to 4 buttons, by app for smartphone / tablet or in
ater to connect controllers that are too far away. Both the combination with app and button respectively. This ensures
Quasar control modules and the Quasar app can be kept up that you can switch the lighting quickly and easily always on
to date by software updates if required. So you always enjoy entering or leaving a room.
the full and updated range of functions.
EASY APP START-UP AND CONTROL

If you want to operate the Quasar modules with a smart-
phone or tablet [Android / iOS, compatible from BT4.2],
download the Quasar app - available free of charge in the
App / Play-Store and and install the app. Then everything
is lightning fast: create a free user account via the intuitive
menu, log in, set up the rooms in which Quasar modules
are installed, scan the assembled and operational cont-
rollers and configure them according to your wishes. Your
smart Quasar network is ready.
