You would like to dim and switch 230V components from universal dimmer switches are ideally suited for simple and
several locations, but do not have the required number problem-free integration for both existing and new instal-
of cores in the existing installation? Then the following lations.
ELTAKO DIMMER UNIVERSAL 400W EUD12NPN-UC
control via standard pushbutton
[control voltage 10V-230V AC+DC]
short keys [on / off], long keys [dimming 0-100-0%]
suitable for R-L-C loads up to 400W, high voltage LEDs
up to 100W, automatic load detection, memory-function,
adjustable minimum load and dimming speed
dimensions L x W x H: 20 x 90 x 70 mm
843042 blue 99,95 €
220-240 max 400
ELTAKO DIMMER UNIVERSAL 400W EUD61NPN-UC
control via standard pushbutton
[control voltage 10V-230V AC+DC]
short keys [on / off], long keys [dimming 0-100-0%]
suitable for R-L-C loads up to 400W, high voltage LEDs
up to 100W, automatic load detection, memory-function,
adjustable minimum load and dimming speed
installation in junction box possible
dimensions L x W x H: 45 x 45 x 18 mm
843043 blue 94,95 €
220-240 max100/
400 W
ELTAKO LED-DIMMSCHALTER ELD61/12-36V
control via standard pushbutton
[control voltage 10V-230V AC+DC]
short keys [on / off], long keys [dimming 0-100-0%]
suitable for 12V/24V/36V LED stripes
and dimmable LED lamps
power 48W bei 12V, 96W at 24V
soft-off for lamp protection
memory-function, adjustable minimum brightness /
dimming speed
dimensions L x W x H: 45 x 45 x 18 mm
843033 blue 89,95 €
12-36 max
96W
