UNIT I INTRODUCTION 6
Pulse measurement – Measurements and sensors – Interfacing Hardware Circuit – Serial Data
Communication

UNIT II PROGRAMMABLE LOGIC CONTROLLERS 9
Introduction –– Principles of operation – PLC Architecture and specifications – PLC hardware
components Analog & digital I/O modules, CPU & memory module – Programming devices – PLC
ladder diagram, Converting simple relay ladder diagram in to PLC relay ladder diagram. PLC
programming Simple instructions – Manually operated switches – Mechanically operated a Proximity
switches - Latching relays

UNIT III APPLICATIONS OF PROGRAMMABLE LOGIC CONTROLLERS. 12
Timer instructions - On delay, Off delay, Cyclic and Retentive timers, Up /Down Counters, control
instructions – Data manipulating instructions, math instructions; Applications of PLC – Simple materials
handling applications, Automatic control of warehouse door, Automatic lubrication of supplier Conveyor
belt, motor control, Automatic car washing machine.

UNIT IV SCADA & SCADA PLC INTERFACING 9
Introduction of SCADA- Buttons, sliders, pipe connections, civil & mechanical parts - Animation
configuration - Text and text control - Graphs, bar charts - SCADA Softwares- PLC SCADA interfacing.

UNIT V CASE STUDIES 9
Sensor interfacing with PLC SCADA - Relay Control – DC motor start stop with timer - Control panel –
Basics of Voltage Frequency control.
TOTAL: 45PERIODS

OUTCOMES:
On completion of the course, the students will be able to
 interpret different sensors and its output
 analyse the architecture of different PLCs and the type of modules
 use different blocks of PLC during programming
 use the different features available with SCADA for monitoring and controlling purpose
 expose to different application of PLC & SCADA interface systems

TEXT BOOKS:
1. Gary Dunning, “Introduction to Programmable Logic Controllers‘’ Thomson Learning, 2001.
2. Boyer,” SCADA: Supervisory Control and Data Acquisition” Independent Learning Module
Book Series, ISA, Dec 1993
3. De. N.K., & Sen. P.K “Electric Drives”, Prentice Hall India Pvt Limited 2002

REFERENCES:
th
1. Bolton, “Programmable Logic Controllers” 5 Edition Newnes,2009
2. Parr, “Programmable Controllers: An Engineers Guide”, 3rd Edition, Elsevier, Indian Reprint,
th
2013 Petruzella , "Programmable Logic Circuits" 4 Edition, TATA McGraw hill, 2016
3. https://www.rfideas.com/solutions/industries/manufacturing
4. http://www.sitech-bitdriver.com/tech/drawings/scada.pdf
