                bonding- TAB and flip chip- Test process and automatic test equipment- test economics and product quality-
                fault modeling.

                UNIT II       SEMICONDUCTOR PACKAGES AND ANALOG TESTING                   9
                Single  chip  packages  or  modules  (SCM),  Commonly  used  packages  and  advanced  packages-  Materials  in
                packages,  Thermal  mismatch  in  packages,  Multichip  modules  (MCM)-types-  System-in-package  (SIP),
                Packaging roadmaps, Hybrid circuits, Electrical Design considerations in systems packaging, Interconnection.
                Memory Test, DSP Based Analog and Mixed Signal Test, Model based analog and mixed signal test, delay
                test, IIDQ test.

                UNIT III    CAD FOR PRINTED WIRING BOARDS AND DIGITAL TESTING             9
                Introduction  to  CAD  and  its  Benefits-Design  rules,  Design  for  Reliability-  Printed  Wiring  Board
                Technologies,  Board-level  packaging  aspects-  Review  of  CAD  output  files  for  PCB  fabrication-  Photo
                plotting and mask generation- Process flow-chart- Vias, PWB substrates, Surface preparation, Photo resist and
                application  methods,  UV  exposure  and  developing,  Printing  technologies  for  PWBs-  PWB  etching,  PWB
                etching,  Resist  stripping,  Screen-printing  technology-Through-hole  manufacture  process  steps,  Panel  and
                pattern plating methods, solder mask for PWBs, Multilayer  PWBs,  Logic and fault simulation, testability
                measures- combinational and sequential circuit test generation.

                UNIT IV SURFACE MOUNT TECHNOLOGY AND DESIGN FOR TESTABILITY       9
                SMD  benefits;  Design  issues,  Introduction  to  soldering-  Reflow  and  Wave  Soldering  methods  to  attach
                SMDs,  Solders,  Wetting  of  solders,  Flux  and  its  properties,  Defects  in  wave  soldering,  Vapour  phase
                soldering, BGA soldering and Desoldering /Repair, SMT failures, SMT failure library and Tin Whisker, Tin-
                lead  and  lead-free  solders,  Thermal  profiles  for  reflow  soldering,  Lead  freevAlloys,  Lead-free  solder
                considerations,  Thermal  Design  considerations  in  systems  packaging.  Analog  test  bus,  Fault  Dictionary,
                Diagnostic  Tree,  Testable  System  Design,  Core  Based  Design  and  Test  Wrapper  Design,  Test  design  for
                SOCs.

                UNIT V EMBEDDED PASSIVES TECHNOLOGY AND LOADED BOARD TESTING   9
                Introduction  to  embedded  passives,  Need  for  embedded  passives,  Design  Library,  Embedded  resistor
                processes, Embedded capacitors, Processes for embedding capacitors, Case study examples. Unpowered short
                circuit tests, unpowered analog tests, Powered in-circuit analog, digital and mixed signal tests, optical and X-
                ray inspection procedures, functional block level design of in-circuit test equipment.
                                                                                       TOTAL = 45 PERIODS

                OUTCOMES:
                Upon completion of the course, students will be able to
                    •   Explain different testing equipment’s.
                    •   Design the different testing schemes for a circuit.
                    •   Discuss the need for test process.
                    •  Given an electronic system PCB or integrated circuit design specifications, the student should be able
                       to  recommend  the  appropriate  packaging  style  to  be  used,  and  propose  a  design  procedure  and
                       solution for the same.
                    •   Design Embedded passive circuits.

                TEXT BOOKS:
                1.Rao R. Tummala, “Fundamentals of Microsystems Packaging”, McGraw Hill, NY, 2001
                2.Michael L. Bushnell and Vishwani D. Agarwal, “Essentials of Electronic Testing for Digital, Memory &
                Mixed-Signal VLSI Circuits”, Springer, 2006.

                REFERENCES:
                1.  William D. Brown, “Advanced Electronic Packaging”, IEEE Press, 1999.
                2.   DimitrisGizopouilos , “Advances in Electronic Testing” , Springer 2006.
