LED Wireless AC Indoor

Features Application

• Smooth and even brightness without glaring • Commercial lighting Lighting LED Indoor

• Up to 40,000 hours of rated life • Of cial lighting
• 4-step dimming (100%-70%-40%-15%) is freely • Meeting room and parking lot lighting
applied to multi applications

• High quality, CE certi cated

Mechanical Drawing Fixture-White LED Lighting

595.0
18.6

595.0 Fixture-RGB LED Lighting

15.6

Photometric Data Controller Lighting

Candle Power Distribution Diagram Illuminance Distribution Unit: Lux
95° 50 95° 1036 lx 309 cm 312 cm
90° 90° 1 m
85° 50 85° 2 m 259 lx 618 cm 624 cm
80° 150 80° Converter DMX Driver /
3 m 115 lx 928 cm 936 cm
75° 250 75°
70° 350 70° 4 m 65 lx 1237 cm 1248 cm
65° 450 65° 41 lx 1546 cm 1560 cm
5 m
60° 550 60° 29 lx 1855 cm 1873 cm
650 6 m
55° 55°
750 7 m 21 lx 2165 cm 2185 cm
cd=1038.99
50° 850 0°(114.69°) 50° 8 m 16 lx 2474 cm 2497 cm
950 90°(111.21°)
45° 180°(114.57°) 45° 9 m 13 lx 2783 cm 2809 cm
1050
10 m 10 lx 3092 cm 3121 cm
40° 35° 30° 25° 20° 15° 10° 5° 0° 5° 10° 15° 20° 25° 30° 35° 40°
Vert.Spread: 114.2 deg. Horiz. Spread: 114.7 deg. Accessory
