LED Dimming AC Indoor

Features Application

• Smooth and even brightness without glaring • Commercial lighting Lighting LED Indoor

• Up to 40,000 hours of rated life • Of cial lighting
• 4-step dimming (100%-70%-40%-15%) is freely • Hospital, meeting room and school lighting
applied to multi applications

• High quality, CE certi cated

Mechanical Drawing Fixture-White LED Lighting

R 18.0 Fixture-RGB LED Lighting

595.0 ±1.0 500.5 ±1.0

500.5 ±1.0
595.0 ±1.0 37.3 ±1.0 Controller Lighting

Photometric Data

Candle Power Distribution Diagram Illuminance Distribution Unit: Lux

90° 90° 1 m 1016 lx 312 cm 313 cm
85° 100 85° Converter DMX Driver /
80° 200 80° 2 m 254 lx 624 cm 626 cm
75° 75° 3 m 113 lx 936 cm 939 cm
300
70° 70°
400 4 m 63 lx 1247 cm 1251 cm
65° 65°
500 5 m 41 lx 1559 cm 1564 cm
60° 600 60°
6 m 28 lx 1871 cm 1877 cm
55° 700 55°
800 7 m 21 lx 2183 cm 2190 cm
50° cd=1017.86 50°
900 0°(114.82°) 8 m 16 lx 2495 cm 2503 cm
45° 1000 90°(111.65°) 45° 9 m 13 lx 2807 cm 2816 cm
1100 180°(114.83°)
40° 35° 30° 25° 20° 15° 10° 5° 0° 5° 10° 15° 20° 25° 30° 35° 40° 10 m 10 lx 3119 cm 3119 cm Accessory
Vert.Spread: 111.8 deg. Horiz. Spread: 111.8 deg.
