Lighting Controller
COLORPRO
ColorPro
Dimension 212.8 mm(L) x 40 mm(W) x 101 mm(H)
5001-B0 Control 4,096 RGB pixels
Capacity
Lighting Effect • 16 built in segments
Program • 256 user-de ned segments
ARC5001-B0 Lighting Controller • 200 compound segments
Synchronization Parallel-linked up to 20 sets
COLORPRO ARC5001-B0 lighting controller transmits
signals in DMX512 standard communication format or • USB
Communication
DMX+ (exclusive DMX+ of ARC SSL) communication Interface • Ethernet (RJ-45)
• RS-485
formatto control the variation of brightness and color
Communication
of DMX512/DMX+ lighting fixtures. When a lighting Protocol DMX 512 / DMX+
program is produced by software, it will be downloaded Software
through USB, LAN and RS485 port communication Supported Lightshow Screen
and stored in the controller, or stored in SD card and Power Input DC 8V~ 24V (3W)
then inserted into the controller. The lighting program
to be played can be selected by controller frontpanel Operating Operating Temperature : 0~60 Ċ
Environment Operating Humidity : 10%~90% non-condensing (RH)
operation. The controller is mainly applied to LED lamp
walls, LED advertising light boxes and LED landscape Certi cation CE/FCC
lighting.
