Lighting Controller

DC SPI Lighting Controller
DC SPI
Dimension 141 mm(L) x 55 mm(W) x 30 mm(H)
3105-C0 Control Capacity 1,024 RGB pixels

Lighting • 8 built-in segment
Program • 8 user-de ned segment
ARC3105-C0 DC SPI Lighting Controller • 1 compound segment from 1-16 segments

Synchronization Parallel-linked up to 20 sets
ARC3105-C0 DC SPI lighting controller is designed
Communicaion
for the LED advertising and indoor commercial lighting Interface RS485
applicatrion. The adjustment of the program, speed, Communication SPI
and brightness in any occasions can be achieved with Protocol
software LightShow Screen and RF module ( optional ). Software Lightshow Screen
supported
ARC3105-C0 DC SPI lighting controller lets
Power Input 12-40 VDC
you create splendor lighting program on almost any
interior or exterior surface in a cost-effective way. Operating Opearting Temperature : -20 - 60 Ċ
Environment Operating Humidity : 10% - 95%

Certi cation IP66
