GAS BURNER
• AFTER SALES SERVICE • The placement of the burners allows use of pans up to 40 cm in diameter
Characteristics of the product range
• The pilot flame is protected inside the main burner
• The single cast iron pan support are dishwasher-size
• The watertight pressed worktop is in 1mm AISI 304 stainless steel with
drawn edges allows an efficient burning and prevents liquid overflowing,
ensuring easier cleaning operations
• The removable burners in enamelled cast iron and the brass burner caps
of 5.5kW or 7kW each have horizontal self-stabilizing flame, to cook
safely and for simpler maintenance
• Each burner has an adjustable power range, from a minimum of 1.5kW
to a maximum of 5.5 / 7kW, to get maximum flexibility
• Rounded corners
• Protected pilot flame
• 60% certified efficiency
• Watertight pressed worktop
• KITCHEN CONSULTANT Model: MG7G2A77XS Model: MG7G4A77XS • New cast iron pan support (individual)
• High power: flex burner of 5.5kW or 7kW
• Cast iron removable burners with self-stabilizing flame
• Horizontal flame: uniform heat distribution, also ideal for delicate cooking
• Maximum flexibility thanks to an adjustable power range,
to satisfy every need

• LARGEST STOCKIST Model Dimensions(mm) No. of burners(5.5kW) Gas consumption(Btu/hr) GAS BURNER
Net weight(kg)
2
W400 x D700 x H850
41
37559
MG7G2A77XS
W700 x D700 x H850
75117
4
62
MG7G4A77XS

• Precision brass valving
• ONLINE LOWEST PRICE Model: OB2(S) Model: OB2 Model: OB4 • • Automatic piezo ignitor
• Free standing designed (*FS)
• Stand by manual lighting holes
• Removable cast iron top grate
• Even heat high input 20,000Btu each
• Drip pan is easily removable for cleaning
• Full stainless steel constructed body, hygienic
and easy to keep clean
• Stainless steel feet with adjustable height up
to 50mm (free standing models)

• OVER 25,000 PRODUCTS Model Model: OB6 Dimensions(mm) No. of burners Gas consumption(Btu/hr) Model: OB6FS

Model: OB2FS
Model: OB4FS
Model: OB2(S)FS
Net weight(kg)
2

OB2
28
W300 x D720+60 x H350
40000
OB2(S)
4
80000
W600 x D720+60 x H350
OB4
48
6
120000
W900 x D720+60 x H350
OB6
70
2
35
OB2FS W600 x D417+60 x H350 2 40000 28
W300 x D720+60 x H860
40000
OB2(S)FS W600 x D417+60 x H860 2 40000 35
OB4FS W600 x D720+60 x H860 4 80000 56
OB6FS W900 x D720+60 x H860 6 120000 79
