Figure 4.32 Effect of strain rates on the stress-strain curves for the
hybrid of G2/B3/G2 147

Figure 4.33 Effect of strain rates on the stress-strain curves of [G/B]3G 148

Figure 4.34 Effect of strain rates on the stress-strain curves of G2/J3/G2 148

Figure 4.35 Effect of strain rates on the stress-strain curves of [G/J]3G 149

Figure 4.36 Effect of strain rates on the stress-strain curves for hybrid
of G2/F3/G2 149

Figure 4.37 Effect of strain rates on the stress-strain curves of [G/F]3G 150
Figure 4.38 Comparison of stress-strain curves between E-glass/basalt,
-1
E-glass and basalt laminates at 950 s strain rates 151
Figure 4.39 Comparison of stress-strain curves between E-glass/jute, E-
-1
glass and jute laminates at 2000 s strain rate 152

Figure 4.40 Comparison of stress-strain curves between E-glass/flax, E-
-1
glass and flax laminates at 500 s strain rates 152

Figure 4.41 Specific dynamic peak stress of G2/B3/G2, G2/J3/G2 and
G2/F3/G2 154

xviii
