NEW AMAZING PRICE! WIRE MESH SECURITY PARTITION
Never Compromise Quality for Price . . .
MORE FEATURES & QUALITY Exclusive Features Include:
• Free mortise cylinder lock in every door
• Free 3 1 /2”W stiffener post with each
door for superior strength
Create high-visibility security areas with
our easy-to-install partitions. Designed for
unrestricted ventilation and layout flexibility.
Made of 10-gauge wire woven in a 1 1 /2”
diamond pattern with a strong 14-gauge
cold rolled C-channel frame. Wire mesh is
clinched, not welded, into frame for heavy-
duty strength and enhanced appearance.
Panels include floor sockets, nuts, bolts and
detailed assembly instructions. Gray powder
coat finish.
Easy To Assemble!

SAMPLE LAYOUT
MASONRY WALL
5' WALL CLIPS WALL CLIPS 5'
Lowest Price 5' CHANNEL 5' TOP CAPPING MOUNTING ANGLE
FOR ROOMS
FOR ROOMS WITH
STIFFENER
In The CHANNEL SLIDING 20' WITHOUT ROOF ROOF
STIFFENER
GATE
SERVICE
Industry! 5' WINDOW CHANNEL FILL 5'
-A-
5' HINGED STIFFENER GAP 5' *REMEMBER TO ORDER TOP CAPPING*
DOOR
5' 5' 3' 5' 5' Width’ 8’ HIGH 10’ HIGH
23'7" Linear Feet 7" PANEL Model Model
Exclusive Features! 1 SC603320 SC603325
SC603326
2
SC603321
WIRE COMPONENTS 3 SC603322 SC603327
SC603323
SC603328
4
5 SC603324 SC603329
TRANSOM
FILL-A-GAP ADJUSTABLE PANEL
1 /2’’- 12” SC603330 SC603331
1
HINGED DOOR with cylinder lock - 8’H (10’ H room has 2’H transom)
1
Includes 3 /2’’W channel stiffener.
3 SC603332 SC603334
4 SC603333 SC603335
SLIDING GATE with cylinder lock - 8’H (10’ H room has 2’H transom)
FLOOR SOCKETS 3 /2”W CHANNEL CORNER POST HINGED SLIDING Includes three 3 /2’’W channel stiffeners.
1
1
INCLUDED WITH STIFFENER POST DOOR (8’H) GATE (8’H) 3 SC603336 SC603340
PANELS 4 SC603337 SC603341
5 SC603338 SC603342
6 SC603339 SC603343
*TOP CAPPING: 10’ length of top capping (see ordering instructions)
SC603146
CORNER POST
SC603344 SC603345
CHANNEL STIFFENER POST Recommended every 2 panels.
WALL CLIPS TOP CAPPING ADJUSTABLE SERVICE FREE BUILT-
CHANNEL FILL-A-GAP PANEL WINDOW IN MORTISE SC603346 SC603347
BUILD YOUR OWN CYLINDER LOCK T-SPLICE: joint 3 panels in “T” configuration.
SC603130
SLIDING SERVICE WINDOW Includes 12”D shelf.
EASY TO PLAN AND ORDER: Mounted in 5’ wide Panel. Padlockable.
1. Make a floor plan including measurements. Determine height of partition. SC603348 SC603349
2. Indicate doors, gates and service windows and their size and location. Show the WALL CLIPS one set required for each wall connection.
direction of the gate slide or door hinges either left- or right-handed and swinging SC603350
in or out. FLOOR SOCKET Anchors panel.
3. Be sure to utilize as many 5 ft. wide panels as possible for most efficient pricing. SC237623
Add one channel stiffener post for every 2 panels. (Stiffener posts are included with ROOF PANEL Including hardware.
each door and gate.) 1’ x 10’ SC240761
I
4. mportant: You must order TOP CAPPING in 10-foot sections. Calculate the total 5’ x 10’ SC240720
linear feet and round up to the nearest multiple of 10, then divide by 10 for the
number of top capping sections. Example: Actual 63’ 7” linear feet: Order 7 top MOUNTING ANGLE FOR ROOF PANEL 1 required per panel.
capping sections (70 ft. total). 10’ SC240721
5. Adding a roof requires 1 ft. or 5 ft. roof panels (hardware included) and mounting ROOF BEAM
angles. Rooms larger than 20’ x 10’ require a 10’L roof beam. Roof beams can be 10’ SC240722
joined together by using a splice kit when beam requirements exceed 10’L and a ROOF BEAM SPLICE KIT
channel stiffener post is required to support connected roof beams. SC240723
