MOBILE REEL WIRE REEL
DISPENSER CADDY
900 lb. capacity Pays out wire quickly
and easily. Designed for
Store, dispense and cut desired lengths of wire spools of assorted
wire, cable, rope, etc. Each 40’’ long, /8’’ dia. sizes. Includes 8 axles 3 /4”
5
axle holds 150 lbs. and adjusts on 7’’ centers. diameter and 2 axles
Tubular steel construction, 32” x 40” base 1 1 /8” diameter. Rugged
with leveling glides for uneven surfaces. 16 gauge welded steel
66”high. Optional casters add 6 /4’’ to height. frame is constructed of
1
3
Gray enamel finish. Assembles easily. /4” tubing with durable
powder coated bright
orange finish.
SHOWN WITH
OPTIONAL
CASTERS
Model
Model Description SC230002
SC184632 6 axle reel dispenser
SC184631 5’’ polyurethane swivel
brake caster set
SAFETY U-RACK
10,000 lb.
capacity per pair

Ideal for storing bars, channels, angles, pipes etc.
Stacks up to 4 high. Safety pins lock stacked racks
together to help protect employees from injury. Heavy
duty welded steel construction. 25 /4” wide top x 20”
1
STEEL PIN LOCKS high x 4 /4” wide bottom channel.
1
RACKS TOGETHER Model SC952201
VERTICAL SHEET RACK CORROSION RESISTANT
CANTILEVER SHELVING & RACK
Offers 800 lb. capacity per pair of arms. Our Nexelon
finish protects against bacteria, mold, cold weather and
chemicals. 10 Year Limited Lifetime Warranty against rust
and corrosion. 12 gauge steel frame adjusts to 36”, 48”,
60” or 72”W. Frame measures 72”H x 27”D and includes
27”D x 8-1/2”H bottom shelf. Allows arm adjustments at 6”
increments. Cantilever Shelving includes frame, 3 pairs of
WIRE straight arms and 3 wire shelves. Wire Shelves easily rest on
SHELVES straight arms. Configure your own Cantilever Rack using 1
Frame and 24”L Straight Arms to store square or flat items
or 20° Inclined Arms to store pipes and round stock.
Customize
to Your Bulk
Storage Needs!
INCLINE
ARM
Choice of Floor
or Mobile
Stores sheet materials. Includes 3 pairs of 1 3 /16” dia. STRAIGHT ADJUSTABLE
steel pipe uprights at 12”, 26” and 36” heights steel CANTILEVER RACK ARM WIDTH
framed wooden deck with lacquer finish. 1 1 /2”H Model Description 36” - 72”
x 1 /2” thick angle iron frame has rounded safety SC235947 Frame
edges. Provisions included for floor anchoring. SC235948 Straight Arms
Blue enamel finish. Frame sockets permit 3 1 /2” SC235949 20° Incline Arms
upright adjustments (24”W has 7 sockets; 30”W
has 9 sockets). Mobile Rack has 6” mold-on rubber CANTILEVER ADDITIONAL
wheels and 2,000 lb. capacity. SHELVING WIRE SHELVES
W” x D” Model Model
FLOOR RACK MOBILE RACK 36 x 24 SC245644 SC188556E
L” x W” Model Model 48 x 24 SC245645 SC188558E
48 x 24 SC652208 SC652214 60 x 24 SC245646 SC188560E 27” BOTTOM SHELF
60 x 30 SC652213 SC652215 72 x 24 SC245647 SC188564E FOR SMALLER ITEMS
42
