BEST EUROPEAN STYLE
SC241421 PLASTIC
SC252814 SHOWN WITH VALUE!
ADDITIONAL FOLDING PLATFORM TRUCK
REMOVABLE HANDLE
HANDLE Rugged injection molded polypropylene platform
is corrosion resistant and easily cleaned. Underside
of platform is ribbed for extra strength to help
absorb impact. Offset epoxy coated handle and 2
swivel and 2 rigid casters help to ease transport of
materials. Models SC241420 and SC241421 offer
a folding handle for compact storage. Models
SC252812 and SC252814 offer sockets on each
Up to 2000 lb. capacity platform end to add an additional handle.

Cap. Caster Caster Deck ADDITIONAL HANDLE
Model L” x W” Lbs. Dia.” Type Ht.” Model
SC241420 33 x 21 500 4 Polyurethane 6 1 /2 ---
SC241421 37 x 25 500 5 Polyurethane 8 ---
SC252812 36 x 24 1000 5 Mold-On Rubber 8 1 /2 SC252813
SC252814 52 x 25 2000 6 Mold-On Rubber 9 1 /2 SC252815
SC330036 NARROW AISLE
STEEL DECK
TRUCK SHOWN PLATFORM TRUCK
WITH OPTIONAL
SHELF Choose Wood, Steel
or Aluminum Deck!
Handles more merchandise than several hand trucks and
stock carts combined. Narrow deck width design simplifies
movement in confined spaces, aisles or hallways. Six-
wheel caster configuration allows truck to turn on its
own radius. Twin removable handles allow transport of
oversized cargo. Choose steel bound 5 /8” Plywood Deck
with polyurethane finish, or 13 gauge Steel Deck with slip-
proof diamond tread surface, both with 1500 lb. capacity
for maximum strength in toughest applications; two rigid
8” polyurethane wheels and four swivel 4” rubber casters
with a 12” deck height. Durable powder coat finish.
Aluminum Deck truck offers aluminum handles and slip
resistant diamond tread 6063 T5 aluminum surface riveted
to an all-welded aluminum deck. Corrosion resistant and
lightweight truck has 1200 lb. capacity and 9 1 /2” deck
height, and rolls easily on two 6” rigid and four 5” swivel
polyurethane casters. Optional Shelves offer additional
shelf space, as each truck can accommodate two shelves
(350 lb. capacity per shelf).
SC242045
1500 lb. ALUMINUM ADDITIONAL
capacity DECK TRUCK STEEL DECK WOOD DECK STEEL SHELF
SC330038 L’’ x W’’ x H’’ Model Model Model
WOOD DECK 60 x 16 x 63 SC330034 SC168002 SC241690
TRUCK 60 x 24 x 63 SC330036 SC330038 SC241691
ADDITIONAL
ALUMINUM DECK ALUMINUM SHELF
L’’ x W’’ x H’’ Model Model
63 x 16 x 61 SC242045 SC242046
WOOD DECK PLATFORM TRUCK
2400 lb.
capacity

Transport items safely. 51”L x 23 1 /2”W truck has 1 /2” varnished plywood deck with welded
steel frame to handle heavy loads. Complete with twin removable 1” dia. tubular steel
handles with cross-braces to help retain cargo. Rolls smoothly on 2 swivel, 2 rigid roller
bearing wheels. Chip-resistant powder coat finish. Assembles easily.

Model Wheel Type Cap. Lbs. Deck Ht.”
SC241682 6” x 2” Mold-on Rubber 2000 8 1 /2
SC241683 8” x 2” Mold-on Rubber 2400 10 3 /4
SC241684 8” x 2 1 /2”Full Pneumatic 1200 10 3 /4
62
