FURNITURE HARDWOOD DOLLY
DOLLY 1200 lb. capacity
Raise and
Transport Bulky Seasoned and sealed hardwood,
smoothly finished with flush top
Items bolted construction. Four swivel
3950 lb. A hard rubber casters.
capacity OPEN DECK C

CARPETED ENDS
3” CASTER– 4” CASTER–
1000 LB. CAP. 1200 LB. CAP.
Style L” x W” Model Model
A 24 x 16 SC952150 SC952150B
A 36 x 24 SC952152 SC952152B
B 24 x 16 SC952154 SC952154B
B 36 x 24 SC952156 SC952156B
Safely transport furniture, computer equipment or any B C 30 x 18 SC585342 SC585172B
odd-shaped item easily. Simple hand-operated hydraulic C 36 x 24 SC585343 SC585344B
jack raises and lowers loads at controlled speeds. 23”W SOLID DECK D 30 x 18 --- SC952168B
x 2 1 /4”D lift plate raises load to 10”H. Positive ratchet REPLACEMENT CASTERS-Set of 4
mechanism with 16’ nylon strap secures load. Rolls Wheel
smoothly on 6” polyurethane casters. 26 1 /2”L x 16”W x D Model Dia.”
42”H overall and weigh 95 lbs. each. Sold in pairs. SC251444 3
Model SC242044 RUBBER BUMPERS SC251445 4
LIGHTWEIGHT PLASTIC DOLLY STEEL DOLLY

OPEN STEEL L
DECK

1200 lb. K
J capacity PADDED
FLUSH DECK
DECK PULL LOOP
One piece 30”L x 18”W high-impact molded polyethylene dollies are lightweight
and easy to clean. Will not rot, warp or splinter. Steel reinforced in critical areas
for added strength. Four swivel non-marring rubber wheel casters assure easy
mobility. Convenient steel loop allows dolly to be towed with a rope or chain.
Choose flush deck or non-marking rubber padded deck for added cargo protection. Move machinery or heavy Cap.
Model
4” CASTER-1000Lb. Cap 5” CASTER-1200Lb. Cap. cases and cartons. Arc Welded Style L” x W” Lbs. Wheel SC952164
L
1200 Rubber
Steel dolly has 1 1 /2” x 1 1 /2” x
27 x 16
Style Model Wt. Lbs. Model Wt. Lbs. 3 /16” open deck frame with L 27 x 16 1600 Steel SC952165
J SC241344 14 SC241529 15 durable enamel finish and low L 36 x 24 1200 Rubber SC952166
K SC241345 16 SC241530 17 profile 5” deck height. L 36 x 24 1600 Steel SC952167
FULL-PNEUMATIC CASTER
HOW TO SELECT THE PROPER Transport delicate parts and materials virtually on air. Shock-absorbing,
WHEELS AND CASTERS full pneumatic tired, roller bearing wheel absorbs vibrations which
could be harmful to load, while protecting floors. Corrosion-resistant
1
1. SELECT WHEEL TYPE: electroplated casters provide years of dependable service. 4 /2” x 4”
HARD RUBBER - Highly resistant to water, oil and animal plate size with 2 5 /8” to 3” x 3” to 3 5 /8” bolt spacing. Gray rubber tires.
fats. High load carrying ability and floor protection. (6” diameter casters are constructed of black rubber)
STEEL - Carbon steel casting. Unbreakable in normal service. Cap. Width” O.A SWIVEL RIGID
SEMI-PNEUMATIC - For light duty trailers, dollies Lbs. Dia.” /Ply Ht.” Model Model
or hand trucks. “Puncture-proof”, no inner tube. 200 6 2.00/4 7 1 /4 SC241532 SC241531
FULL PNEUMATIC - For handling delicate instruments 300 8 2.80/4 9 3 /4 SC748042 SC748040
or fragile parts. Floats loads over the roughest floors or 330 10 4.10/4 12 1 /2 SC748046 SC748044
obstructions. CASTER KIT - 2 Swivel, 2 Rigid. Capacity lbs. is per kit.
MOLD-ON RUBBER - For full floor protection where greater 1200 8 2.80/4 9 3 /4 SC502592A
capacities, load cushioning and less “load starting” effort is
required. FLOOR LOCK
MOLDED PLASTIC/POLYOLEFIN - For high impact, easy
rolling, floor protection, and capacity. Resistance to many Mount to underside of platform trucks, lift tables and carts to help immobilize
chemicals and heat. while loading or unloading. Simply step down to lock, step again to unlock.
POLYURETHANE - For longer wear, floor protection, high Corrosion resistant zinc-plated steel with 3” rubber footpad. 4 1 /2” x 4” top

capacity and excellent cushioning. plate with slotted holes for 2 5 /8” to 3” x 3” to 3 5 /8” mounting.
2. DETERMINE LOAD CAPACITY per caster by adding load and For Extended Retracted
truck weight and dividing result by number of supporting Model Caster Dia.” Height” Height”
casters. For specific recommendations consult our engineering
department. SC241851A 4 5 5 3 /4 5 1 /16
SC241851B
3. WHEEL DIAMETER - The greater the wheel diameter, the easier SC241851C 6 6 5 /8 5 5 /8
7 5 /8
6 5 /8
it is to move. SC241851D 8 9 5 /8 8 5 /8
