JOYSTICK RIGGING

SMARTCRAFT GPS ANTENNA 400 JOYSTICK: MAIN POWER RELAY HARNESS - 40 FT.
JOYSTICK RIGGING

8M0091565 84-879172T85
SmartCraft GPS Antenna (4.0.12SC) Used with SmartTow Pro SC1000 gauges, Powers CCMs and TVMs for Joystick installations. Used in addition to 5 amp clean
MercMonitors, and VesselViews 4 and 7. power harness. (40 ft. long)
Sends CAN H and CAN P GPS data for use with GPS SmartTow and Joystick
Piloting boats with Auto Pilot. Software 4.0.12SC JOYSTICK: MAIN POWER RELAY HARNESS - 60 FT.
84-879172T86
COMBO GPS/IMU Powers CCMs and TVMs for Joystick installations. Used in addition to 5 amp clean
power harness. 60 ft. long
MAIN POWER RELAY HARNESS (DUAL HELM)

8M0105389
Combo GPS/IMU used in Joystick Piloting applications, included in the rigging kits
Service component for Joystick Piloting applications circa mid‑2016 and later
84-8M0047753
CAN H GATEWAY Power for upper helm CCM for Joystick installations. Tees off of lower helm main
power relay harness. (20 ft. long)
84-8M0047754
Power for upper helm CCM for Joystick installations. Tees off of lower helm main
power relay harness. (40 ft. long)
84-8M0047755
Power for upper helm CCM for Joystick installations. Tees off of lower helm main
power relay harness. (60 ft. long)
10 PIN TO 5 PIN CAN H ADAPTER

8M0095543
Utilized in Joystick applications (typically included in the full rigging kit), provides an
interface between CAN H GPS & IMU and the NMEA2000 device (approved chart
plotter). Allows for adavanced features such at Waypoint Sequencing,
AutoHeading and SkyHook
Can be used on any Joystick application as an interface between CAN H and
NMEA0183 OR NMEA2000. Not required for systems with the VesselView 4 or 7
display RTM5 software release that are using a NMEA2000 approved chartplotter
JOYSTICK: MAIN POWER RELAY HARNESS - 20 FT.
84-8M0115495
Adapter harness that goes from 10 pin SmartCraft connector to 5 pin CAN H
connector
Used for certain Joystick applications

84-897345T08
Powers CCMs and TVMs for Joystick installations. Used in addition to 5 amp clean
power harness. (20 ft. long)
