INSTRUMENT EXTENSION HARNESS
14 PIN DATA HARNESSES
EXTENSION HARNESS - 14 PIN ELECTRICAL

84-860615002
4 m (13.2 ft.) harness, 21 pin Deutsch connector
Fits D1.7L , 2001 and newer D4.2L, D2.8L and 4.2L ES and EI; 1997 and newer
D7.3L ES diesel models. 84-892451T06
84-860616002 6 ft. (1.8 meter) data harness. Provides data link between DTS engine and
command module harness.
8 m (26.3 ft.) harness, 21 pin Deutsch connector Works with all engines equipped with 14‑pin connectors.
Fits MCM/MIE D1.7L ; also 2001 and newer D4.2L, D2.8L and 4.2L ES & EI diesel
models; also fits 1997 and newer D7.3L Electronic diesel models 84-892451T10
10 ft. (3.0 meter) data harness. Provides data link between DTS engine and
HARNESS ADAPTER command module harness.
Works with all engines equipped with 14‑pin connectors.
84-892451T15
15 ft. (4.6 meter) data harness. Provides data link between DTS engine and
command module harness.
Works with all engines equipped with 14‑pin connectors.
84-892451T20
20 ft. (6.1 meter) data harness. Provides data link between DTS engine and
command module harness.
Works with all engines equipped with 14‑pin connectors.
84-892451B20
20 ft. (6.1 meter) data harness. Provides data link between DTS engine and
84-860622 command module harness.
Bulk Pack ‑ 6 harnesses to a box.
21 pin female Deutsche connector to 8 pin & 9 pin female connector Works with all engines equipped with 14‑pin connectors.
Adapts newer diesel engines with 21 pin Deutsch connector engine harnesses to
older diesel engines instrument harness with the 8 pin & 9 pin connectors. Priced individually, sold @ multiples of 6
84-892451T25
HARNESS ADAPTER 25 ft. (7.6 meter) data harness. Provides data link between DTS engine and
command module harness.
Works with all engines equipped with 14‑pin connectors.
84-892451T30
30 ft. (9.1 meter) data harness. Provides data link between DTS engine and
command module harness.
Works with all engines equipped with 14‑pin connectors.
84-8M0149640
35 ft. (10.7 meter) data harness. Provides data link between DTS engine and
command module harness.
Works with all engines equipped with 14‑pin connectors.
84-892451T40
84-860624 40 ft. (12.21 meter) data harness. Provides data link between DTS engine and
Adapts engine harness 84‑806389A 2 (used on 1994‑1997 D3.0L, D3.6L and command module harness.
D4.2L diesel models) to extension harnesses 84‑860615 or 84‑860616. Works with all engines equipped with 14‑pin connectors.
HARNESS ADAPTER 14 PIN EXTENSION HARNESS

84-860625 84-8M0131369
Adapts engine harness 84‑855509 or 84‑803626 (used on 1997 & up D2.8L and 5 ft. 14‑pin Extension Harness
D4.2L ES and EI diesel models) to extension harnesses 84‑860615 or 84‑860616. All Diesel Engines
21 pin to 17 pin connector
