Page 632 - US ACCESSORIES GUIDE (2019)

ELECTRICAL

ACCESSORY HARNESSES HARNESS - POWER 25 FT

DTS CLEAN POWER - HELM - 10 FOOT ELECTRICAL

84-889244T01
25 ft Clean Power harness with heavy gauge (10 ga) wire for lower voltage drop.
Use from crank battery to 2 pin connector on engine. DTS and MCM EC engines.
84-8M0127681
10 foot DTS clean power for use at the helm. ACCESSORY POWER HARNESS / RELAY HARNESS KIT
All DTS and Joystick applications. When crank batteries are located near the helm
or mitigation of excessive voltage drop is desired.
DTS CLEAN POWER - HELM - 15 FOOT
84-8M0127682
15 foot DTS clean power for use at the helm
All DTS and Joystick applications. When crank batteries are located near the helm
or mitigation of excessive voltage drop is desired
HARNESS- 25 FT CLEAN POWER

84-899785K15
Used to provide accessory power to auxiliary loads when the keyswitch is in the
"Run" or "Accessory" positions. Includes 40 amp relay, harness and 15 ft power
cable with 40 amp fuse and three pole terminal block.
Used on 14‑pin boat harnesses that have a 3‑pin accessory power relay
connector.
ACCESSORY POWER HARNESS / RELAY HARNESS KIT

84-896333T25
25 ft. harness. Used to reduce voltage drop when battery is located near the helm
of the boat. Connects to junction box at the helm.
Used on all DTS Engines
POWER HARNESS-ENGINE

84-899785K30
Used to provide accessory power to auxiliary loads when the keyswitch is in the
"Run" or "Accessory" positions. Includes 40 amp relay, harness and 30 ft power
cable with 40 amp fuse and three pole terminal block.
Used on 14‑pin boat harnesses that have a 3‑pin accessory power relay
connector.

84-8M0113732
15 foot DTS clean power harness. Used when battery is located near the the
engine. Connects to 2 pin clean power connector on the engine.
All L4 SC Verados, 200/225 Opti DTS, 20 in. L6 Verados and MCM DTS and EC
engines have this harness as part of the engine package. Must order loose for 25
in. and 30 in. L6 Verados.
