STEERING

HYDRAULIC STEERING - COMMON TO POWER HYDRAULIC HELM PUMP -Q/S
STEERING SYSTEMS

These parts are used to install Hydraulic Steering with the Power
Steering components. Use hoses 8M0046914 thru 8M0046932 are the
hoses that go with these cylinders and helms. All fittings are Power
steering fittings found in the Power Steering section.

CYLINDER - HYDRAULIC OR POWER STEERING

64-891665Q01
Front Mount 1.5 cu in displacement. Approximately 5 turns lock to lock on singles
and 10 on dual cylinders
Compact design
Built‑in valve for positive rudder lock
Integral relief valve for over pressure protection
Hydraulic Steering for Verado 135 to 175‑4 stroke engines
Also can be used on OptiMax with Mercury hydraulic cylinder and hoses. Also can
be used on OptiMax with Mercury hydraulic cylinder and hoses Also can be used
on 75‑115 4 stroke and 1.5L opti 75‑115 HP
898349A11 HYDRAULIC HELM PUMP -Q/S
Cylinder designed to meet all Power Steering strength and performance
requirements. This cylinder is the most robust design in the market. Includes all
STEERING hardware to mount this cylinder including the strongest bolts to attach to the
engine.
Verado 175‑200 ‑ both Power Steering or Hydraulic V6/1.5 Opti Max Hydraulic ‑
1.5L Opti needs to order arm 898082A03 to provide clearance
75‑150 4 stroke engines.
CYLINDER - HYDRAULIC OR P/S- COUNTER ROTATION

64-891665Q04
Front Mount 2.0 cu in displacement. Approximately 4 turns lock to lock on singles
and 8 on dual cylinders
Compact design
Built‑in valve for positive rudder lock
Integral relief valve for over pressure protection
Hydraulic Steering for Verado 135 to 200‑4 stroke engines
Also can be used on OptiMax with Mercury hydraulic cylinder and hoses
898349A14 64-891665Q05
Port ot counter rotation cylinder designed to meet all Power Steering strength and Front Mount 2.4 cu in displacement. Approximately 3 turns lock to lock on singles
performance requirements. This cylinder is the most robust design in the market. and 6.5 on dual cylinders
Includes all hardware to mount this cylinder including the strongest bolts to attach Compact design
to the engine Built‑in valve for positive rudder lock
Verado 135‑200 ‑ both Power Steering or Hydraulic. Multiple Engines Integral relief valve for over pressure protection
V6/1.5 Opti Max Hydraulic ‑ 1.5L Opti needs to order arm 898082A03 to provide Hydraulic Steering for Verado 135 to 200‑4 stroke engines
clearance 75‑115 4 stroke engines Multiple OtiMax engines ‑ P/S 150 4 Stroke Also can be used on OptiMax with Mercury hydraulic cylinder and hoses
engines.
CYLINDER - BIG TILLER

898349A15
Cylinder designed to meet all Power Steering strength and performance
requirements. This cylinder is the most robust design in the market. Includes all
hardware to mount this cylinder including the strongest bolts to attach to the
engine.
Big Tiller Cylinder ‑ 75‑115 4 Stroke, 75‑115 1.5L Opti, 135‑250 2.5L/3.0L Opti
and 135‑200 4 Cylinder Verado
