HISTORICAL PROPELLER CHARTS

Mariner‑Thruster Direct Drive
Trolling Motor
Nut 79719 ‑ NLA Washer 26‑72462 Pin 17‑70733

Part No. Diameter Pitch Material Blades Rotation Status or Supersession
17530A__ 9 3.2 PL BL 2 RH 18022A5
18530A__ 9-1/4 3.2 PL CL 2 RH 18022A5
18022A__ 9-1/4 3-1/4 PL BL 2 RH 18022A5
18428A5 9-1/4 3-1/4 PL CL 2 RH AVAIL.
18512A__ 9-1/4 3-1/4 PL CL 2 RH 18428A5
18022A5 9-1/4 3 PL BL 2 RH AVAIL.

Mariner‑R33, RX33, T33, R45, RL45, RX45, T45
Trolling Motor
Nut 818911‑‑2 Washer 23‑35935 Pin 17‑70733

Part No. Diameter Pitch Material Blades Rotation Status or Supersession
813728A__ 11 5 PL BL 2 RH
813730A__ 11 5 PL CL 2 RH
Mariner‑Thruster (MotorGuide)(Machete)
Trolling Motor
Part No. Diameter Pitch Material Blades Rotation Status or Supersession
824236T 9-1/2 2-5/8 PL CL 2 RH AVAIL.
801889 10 3-1/2 PL CL 2 RH MAF12406
Mariner V‑6 Models (W/Large Gearcase 4‑3/4 Inch)
Thrust Hub 12‑835467Q01 Tab Washer 15‑816629Q Washer 12‑31211A3 Nut 11‑52707Q1

Part No. Diameter Pitch Material Blades Rotation Status or Supersession
78126A4 13-3/8 25C AL 3 RH N.L.A.
78126A40 13-3/8 25C AL 3 RH N.L.A.
79796A 4 13-3/8 25C SS 3 RH NLA
79796A 5 13-3/8 25C SS 3 RH NLA
16322A 5 13-3/8 25C SS 3 RH NLA
75724A 4 13-1/2 23C SS 3 RH
16321A 5 13-1/2 23C AL 3 LH
16320A 5 13-1/2 23C AL 3 RH HISTORICAL PROPELLER CHARTS
78124A 4 13-1/2 23C AL 3 RH 48-832834A45
78124A40 13-1/2 23C AL 3 RH 48-832834A45
73982A 4 13-3/4 21C SS 3 RH 48- 16318A46
73982A 5 13-3/4 21C SS 3 RH 48- 16318A46
16319A 5 13-3/4 21C SS 3 LH 48- 16318A46
16318A 5 13-3/4 21C SS 3 RH 48- 16318A46
78122A 4 13-3/4 21C SS 3 RH 48-832832A45
78122A40 13-3/4 21C SS 3 RH 48-832832A45
73980A 4 14 19C SS 3 RH 48- 16316A46
73980A 5 14 19C SS 3 RH 48- 16316A46
16317A 5 14 19C SS 3 LH 48- 16317A46
16316A 5 14 19C SS 3 RH 48- 16316A46
78118A 4 14-1/2 17C SS 3 RH 48-832828A45
78118A40 14-1/2 17C SS 3 RH 48-832828A45
79794A 4 14-1/2 17C SS 3 RH 48- 16314A46
79794A 5 14-1/2 17C SS 3 RH 48- 16314A46
16315A 5 14-1/2 17C SS 3 LH 48- 16315A46
16314A5 14-1/2 17C SS 3 RH 48- 16315A46
78116A 4 16 15C SS 3 RH 48- 78116A45
