Page 933 - US ACCESSORIES GUIDE (2019)

HISTORICAL PROPELLER CHARTS

Part No. Diameter Pitch Material Blades Rotation Status or Supersession
78116A40 16 15C SS 3 RH 48- 78116A45
93272A 4 14-1/2 15C SS 3 RH 48- 16312A46
93272A 5 14-1/2 15C SS 3 RH 48- 16312A46
16312A 5 14-1/2 15C SS 3 RH 48- 16312A46
16312A 4 14-1/2 15 SS 3 RH 48- 16312A46
78114A 4 16 13C SS 3 RH 48- 78114A45
78114A40 16 13C SS 3 RH 48- 78114A45
78112A 4 16 11C SS 3 RH 48- 78112A45
78112A40 16 11C SS 3 RH 48- 78112A45
16320A 4 13-3/8 25 SS 3 RH
16321A 4 13-1/2 23 SS 3 LH 16321A46
16322A 4 13-3/8 25 SS 3 RH 16322A46
16312A 4 14-1/2 15 SS 3 RH 48- 16312A46
16315A 4 14-1/2 17 SS 3 LH 48- 16315A46
16316A 4 14 19 SS 3 RH 48- 16316A46
16317A 4 14 19 SS 3 LH 48- 16317A46
16318A 4 13-3/4 21 SS 3 RH 48- 16318A46

MARINER OUTBOARD

Mariner 2 (6A1)
Cotter Pin 18‑82134M Drive Pin 17‑81896M
Part No. Diameter Pitch Material Blades Rotation Status or Supersession
80409M 7-1/4 5-1/2 AL 3 RH NLA
43110M 7-1/4 5 AL 3 RH NLA
80410M 7-1/4 4-1/2 AL 3 RH AVAIL.
93032M 7-1/4 4 PL 3 RH AVAIL.
Mariner 2.5/3.3 A856377 and Up
HISTORICAL PROPELLER CHARTS Mariner 3.5 (642) Diameter Pitch Material Blades Rotation Status or Supersession
Cotter Pin 18‑95295 Shear Pin 17‑815111 (AL Prop), 17‑815111‑‑1 (PL Prop)

Part No.
RH
PL
3
6
AVAIL.
7-3/8
815083
AL
AVAIL.
RH
7-3/8
6
3
815084
6
7-3/8
AVAIL.
3
815084--1
RH
AL
NLA = 48‑80176M, 48‑80177M, 48‑80304M
Nut 11‑80103M Cotter Pin 18‑82134M Thrust Hub 12‑81855M ‑ NLA Drive Pin 17‑17554M
Part No. Diameter Pitch Material Blades Rotation Status or Supersession
80178M 7-1/2 4 AL 3 RH NLA
82861M 7-1/2 4 AL 3 RH NLA
Mariner 4 (6E) & 5 (6E3)
NLA = 48‑81016M
Nut 11‑859931 Cotter Pin 18‑82132M Drive Pin 17‑17554M
Part No. Diameter Pitch Material Blades Rotation Status or Supersession
96593M 7-1/4 8-1/4 AL 3 RH NLA
96590M 7-1/2 8 AL 3 RH AVAIL.
96592M 7-1/4 7-1/4 AL 3 RH NLA
96591M 7-1/2 7 AL 3 RH AVAIL.
81015M 7-1/4 6-1/2 AL 3 RH NLA
