Page 134 - Latin America Accessories Guide (2020) - 8M0163252
P. 134
MERCRUISER
Model CID/ #Cyl Type of Ignition Year Range Serial # Range Spark Plug Spark Plug Gap
4.3LX 262/ V-6 Thunderbolt IV 1988 - 1993 0B775130 - 0F001219 33-898264001 .035
4.3LX 262/ V-6 Thunderbolt IV 1993 - 1996 0F001220 - 0F802999 33-898264001 .040
4.3LX (Gen +) 262/ V-6 Thunderbolt IV 1996 - 1997 0F803000 - 0K999999 33-862029 .045
4.3LXH (Gen +) 262/ V-6 Thunderbolt IV 1996 - 1997 0F803000 - 0K999999 33-862029 .045
4.5L MPI 275/ V6 Mercury 2014 - 2019 2A441953 and up 33-8M0095454 .051
215 MCM & MIE (Ford) 302/ V-8 Autolite 1970 - 1972 2781153 - 3563181 N.L.A. .030
215 MCM & MIE (Ford) 302/ V-8 Mallory 1970 - 1972 2781153 - 3563181 33-813425 .030
225 MCM & MIE (Ford) 302/ V-8 All 1973 - 1974 3385721 - 4166999 33-813425 .030
888 (Ford) 302/ V-8 All 1971 - 1977 3108723 - 4887829 33-813425 .030
190 (8 cyl.) 283/ V-8 Delco 1963 - 1964 1564539 - 1730903 N.L.A. .035
198 MIE 305/ V-8 Mallory 1977 4776402 - 4931099 33-898264001 .035
200 305/ V-8 Thunderbolt IV 1985 - 1987 6899058 - 0B774444 33-898264001 .035
228 305/ V-8 Mallory 1977 - 1982 4765100 - 6218461 33-898264001 .035
228 305/ V-8 Thunderbolt IV 1983 - 1984 6218462 - 6899268 33-898264001 .035
228 MIE 305/ V-8 Mallory 1977 - 1980 4765100 - 5907057 33-898264001 .035
230 305/ V-8 Thunderbolt IV 1985 - 1987 6899269 - 0B773739 33-898264001 .035
230 MIE (LH) 305/ V-8 Thunderbolt IV 1981 - 1987 5907058 - 0B788151 33-898264001 .035 MERCRUISER
230 MIE (RH) 305/ V-8 Thunderbolt IV 1981 - 1987 5907058 - 0B788151 33-898264001 .035
5.0L 305/ V-8 Thunderbolt IV 1988 - 1995 0B774445 - 0F600999 33-898264001 .035
5.0L (Gen +) 305/ V-8 Thunderbolt V 1998 - 2004 0L015751 - 0W300009 33-862029 .045
5.0L TKS 305/ V-8 Thunderbolt V 2004 - 2010 0W300010 - 1A607561 33-862029 .060
5.0L EFI (Gen +) 305/ V-8 Delco & Mercury - HEI 1998 - 2001 0L012052 - 0M299999 33-862029 .045
5.0L MIE (LH) 305/ V-8 Thunderbolt IV 1988 0B788152 - 0C396832 33-898264001 .035
5.0L MIE (RH) 305/ V-8 Thunderbolt IV 1988 0B788152 - 0C396832 33-898264001 .035
5.0L MPI 305/ V-8 Delco - HEI 2002 - 2014 0M300000 - 2A445009 33-8M2018369 .060
5.0L MPI EC 305/ V-8 Delco - HEI 2008 - 2014 1A300000 - 2A444777 33-8M2018369 .060
5.0LX 305/ V-8 Thunderbolt IV 1988 - 1995 0B773740 - 0F600999 33-898264001 .035
898 305/ V-8 Mallory 1977 - 1982 4762210 - 6218461 33-898264001 .035
898 305/ V-8 Thunderbolt IV 1983 - 1984 6218462 - 6899057 33-898264001 .035
225 (GM) 327/ V-8 Delco 1963 - 1969 1539620 - 2694014 N.L.A. .035
225 MIE (GM) 327/ V-8 Thunderbolt 1968 2278647 - 2694014 33-813415 N/A
250 MCM & MIE 327/ V-8 Thunderbolt 1968 - 1969 2314301 - 2639854 33-813415 N/A
250 350/ V-8 Mallory 1977 4768000 - 4908849 33-898264001 .035
255 MCM & MIE (GM) 350/ V-8 Mallory & Mercury 1975 - 1976 3258728 - 4767999 33-898264001 .035
260 350/ V-8 Mallory 1978 - 1982 4908850 - 6218461 33-898264001 .035
260 350/ V-8 Thunderbolt IV 1982 - 1987 6218462 - 0B773304 33-898264001 .035
260 MIE (LH) 350/ V-8 Thunderbolt IV 1981 - 1987 5907058 - 0B788151 33-898264001 .035
260 MIE (RH) 350/ V-8 Thunderbolt IV 1981 - 1987 5907058 - 0B788151 33-898264001 .035
270 MCM & MIE 350/ V-8 Thunderbolt 1969 - 1972 2851074 - 3385720 33-813415 N/A
280 TRS 350/ V-8 Mercury 1975 4176250 - 4499390 33-898264001 .035
280 TRS 350/ V-8 Mallory 1976 4499391 - 4770199 33-898264001 .035
300 350/ V-8 Thunderbolt IV 1985 - 1986 6668677 - 0B430367 33-898264001 .035
320 EFI 350/ V-8 Thunderbolt IV 1987 - 1989 0A543604 - 0C622418 33-898264001 .035
350 Mag. Alpha 350/ V-8 Thunderbolt IV & V 1986 - 1997 0A635178 - 0K999999 33-898264001 .035
350 Mag. Alpha EFI (Gen+) 350/ V-8 Delco - HEI 1996 0K001509 - 0K999999 33-862029 .045
350 Mag. Bravo MPI 350/ V-8 Delco - HEI 1995 0F415189 - 0F601999 33-898264001 .035
350 Mag. Bravo MPI (Gen+) 350/ V-8 Delco - HEI 1996 - 1997 0F602000 - 0K999999 33-862029 .045
350 Mag. EFI Ski 350/ V-8 Delco - HEI 1994 - 1997 0F215561 - 0K999999 33-862029 .045
350 Mag. MPI (Gen+) 350/ V-8 Delco - HEI 1998 0L010019 - 0L325952 33-862029 .045
2020 Mercury Precision Parts & Accessories Guide 125
