ELECTRICAL

ACCESSORY RELAY KIT JACKPLATE HARNESS ASSEMBLY

84-888429K11 84-881133T 1
Used in conjunction with accessory power harness to provide power to auxiliary Two 5 pin connector harness to 4 bullet (2 male, 2 female) connectors and 3 ring
loads. terminals.
Used on 14‑pin boat harness's that have a 3‑pin accessory power relay connector. For jackplate control.
TERMINAL BLOCK
IGNITION KEY SWITCHES
KEY SWITCH ASSEMBLY

86-889679 ELECTRICAL
3 pole terminal block
Useful for up to 40 Amp circuit connections, used in Accessory Power kits
54212A 7
ACCESSORY RELAY HARNESS KIT 3 ft.(915 mm) harness with ring terminals. Mounts in a 2‑1/8 in.(54 mm) hole
Fits all MCM/MIE gasoline and diesel engines.
KEY SWITCH ASSEMBLY

84-888429K12
Used to provide accessory power to auxiliary loads. Cable is connected to the
junction box and provides power to loads when the key switch in in the "Run"
position. Includes 40 amp relay and harness and 3 pole terminal block. F5H268
For dash mount installations in panels up to 1/2 in.(12.7 mm). "Push to choke"
TVS NOISE SUPPRESSION HARNESS feature.
Fits all electric start Force outboards.
KEY SWITCH ASSEMBLY

84-8M0072192
Reduce noisy voltage spikes from Mercury solenoid coils (trim & tab).
Kit contains 2 harnesses that are used across solenoid coils to help reduce
electrical noise. F5H078
For dash mount installations in panels up to 1‑7/16 in.(36 mm). "Push to choke"
feature.
Fits all electric start Force outboards.
