P. 745
STEERING
DUAL ENGINE TIE BAR KIT TILT STEERING HELM
96708A 4 64-879686
Used with power steering cylinder mounted on the port transom plate. Adjusts from 270 Degree Steering Helm.
29 in.(737 mm) to 37‑1/2 in.(952 mm) Fits all Jet Drive models
Fits 1983 and newer R/MR/Alpha One/Gen II and Bravo models, except D7.3L
diesel. BEZEL KIT
JET DRIVE 135 & 270 DEG. STEERING SYSTEM
The 135 deg. system allows 135 degrees rotation of the steering wheel
(3/8 turn lock to lock). The 270 deg. system allows 270 degrees rotation
of the steering wheel (3/4 turn lock to lock).Order helm, bezel, and
steering cable separately. If the size required is not listed, use the next
larger size.
STEERING HELM
809485
Fits all Jet Drive models
STEERING CABLE
809486
135 Degree Steering Helm.
Fits all Sport Jet models, except V‑6 models.
STEERING HELM 64-835457A11
STEERING 11 ft.(3.4 m) 60 series cable with 5/16‑24 end threads. Includes steering cable
bellows kit.
Fits all Jet Drive models.
64-835457A13
13 ft.(4.0 m) 60 series cable with 5/16‑24 end threads. Includes steering cable
bellows kit.
Fits all Jet Drive models.
64-835457A15
15 ft.(4.6 m) 60 series cable with 5/16‑24 end threads. Includes steering cable
bellows kit.
850699 Fits all Jet Drive models.
270 Degree Steering Helm. 64-835457A17
Fits all Jet Drive models 17 ft.(5.2 m) 60 series cable with 5/16‑24 end threads. Includes steering cable
bellows kit.
Fits all Jet Drive models.
64-835457A19
19 ft.(5.8 m) 60 series cable with 5/16‑24 end threads. Includes steering cable
bellows kit.
Fits all Jet Drive models.
64-835457A21
21 ft.(6.4 m) 60 series cable with 5/16‑24 end threads. Includes steering cable
bellows kit.
Fits all Jet Drive models.
736 Phone: 954-744-3500; Fax: 954-744-3535; E-Mail: miami@mercmarine.com
