Page 742 - Latin America Accessories Guide (2020) - 8M0163252

STEERING

Model Year Range Model Notes Country Serial # Range Stbd. Cable Entry Steering Port Cable Entry Steering Required Steering Bracket
Link Rod Attaching Kit Link Rod Attaching Kit
60 FourStroke 2001 - 2007 996 cc. USA 0T178500 - 1B344306 19608A14 19609A 6 816667A 2(2)
60 FourStroke 2001 - 2019 996 cc. BEL 0P094500 and up 19608A14 19609A 6 816667A 2(2)
60 FourStroke 2007 - 2019 CHN 1C000001 and up 19608A14 19609A 6 816667A 2(2)
75-115 FourStroke 2007 - 2019 USA 1B366823 and up 92876A12 N/A N/A
75-115 FourStroke 2007 - 2019 BEL 0P401000 and up 92876A12 N/A N/A
135 thru 275 (V-6) 1980 - 2019 USA 5464486 and up 92876A12 N/A N/A
150 EFI FourStroke 2011 - 2019 USA 1B905505 and up 92876A12 N/A N/A
135-200 Verado (4 2006 - 2019 USA 1B227001 and up (6)
cylinder)
200-300 Verado (6 2005 - 2019 USA 0T980000 and up (7)
cylinder)
(1) Bracket part number listed is without carrying handle.
(2) Bracket already furnished on remote models.
(3) When using port entry Ezy Glide stick steering, order attaching kit 41323A 2.
(4) When using port entry Ezy Glide stick steering, order attaching kit 899659A01.
(5) Steering bracket is part of the steering link rod attaching kit.
(6) Hydraulic Steering is standard.
(7) Power Steering is standard.

DUAL CABLE - SINGLE ENGINE ATTACHING KIT TIE BAR EXTENSION

Tension‑compression only with both cables installed on the starboard
side.
DUAL CABLE ATTACHING KIT

814951 4
Standard Tie Bar Extension Coupler. 18 in.(458 mm). For clearance problems see
optional extension couplers.
Fits Mercury/Mariner with standard cowling clearance. Outboard center line
distance between 26‑1/2 in. thru 30‑1/2 in. (673 mm thru 755 mm)
DUAL ENGINE TIE BAR
92876A 8
Fits Mercury / Mariner 70‑300 hp. outboards (1985 and Newer) and Force 90/120
hp. outboards (1996 and Newer). STEERING
DUAL ENGINE TIE BAR KITS

Dual cables are required for installations of 80 hp. (combined total of
160 hp.) or higher.

TIE BAR EXTENSION

92876A 9
Includes 15 in. (381 mm) extension coupler. Adjusts from 22 in. (560 mm) to 26‑1/2
in. (675 mm). See extension couplers for additional length.
Fits various Mercury/Mariner 70 thru 3.0 Litre outboards with two piece steering
arms.

8M0026098
Standard Tie Bar Extension Coupler. 15 in.(381 mm). For clearance problems see
optional extension couplers.
Fits Mercury/Mariner with standard cowling clearance. Outboard center line
distance between 23‑1/2 in. thru 27‑1/2 in. (597 mm thru 699 mm)
2020 Mercury Precision Parts & Accessories Guide 733
