JOYSTICK RIGGING

JOYSTICK RIGGING INBOARD JOYSTICK ASSEMBLY

8M0118806 717.00
Joystick assembly used in Joystick Piloting for Inboards ‑ single engine
applications, included in the rigging kit.
Service component for Joystick Piloting for Inboards ‑ single engine applications.
JOYSTICK ASSEMBLY

JPI - MAIN STATION - SINGLE ENGINE - DUAL
THRUSTER

8M0118761 1462.84 JOYSTICK RIGGING
Kit includes major components necessary for installation, including harness
connections for use with compatible Vetus thrusters. Thrusters to be
sourced by the builder. Adaptor connection for Side Power thrusters
available separately through Mercury.
Compatible with current Mercury DTS inboard engines. 8M0118808
JPI - MAIN STATION - DUAL ENGINE - DUAL THRUSTER Joystick assembly used in Joystick Piloting for Inboards ‑ dual engine applications,
8M0128123 included in the rigging kits.
Kit includes major components necessary for installation, including harness Service component for Joystick Piloting for Inboards ‑ dual engine applications.
connections for use with compatible Vetus thrusters. Thrusters to be
sourced by the builder. Adaptor connection for Side Power thrusters
available separately through Mercury.
Compatible with current Mercury DTS inboard engines.
JPI - SECOND STATION - DUAL ENGINE - DUAL
THRUSTER
8M0128124
Kit includes major components necessary for installation, including harness
connections for use with compatible Vetus thrusters. Thrusters to be
sourced by the builder. Adaptor connection for Side Power thrusters
available separately through Mercury.
Compatible with current Mercury DTS inboard engines.
JPI - MAIN STATION - DUAL ENGINE - SINGLE
THRUSTER
8M0128125
Kit includes major components necessary for installation, including harness
connection for use with compatible Vetus thrusters. Thruster to be sourced
by the builder. Adaptor connection for Side Power thrusters available
separately through Mercury.
Compatible with current Mercury DTS inboard engines.
JPI - SECOND STATION - DUAL ENGINE - SINGLE
THRUSTER
8M0128126
Kit includes major components necessary for installation, including harness
connection for use with compatible Vetus thrusters. Thruster to be sourced
by the builder. Adaptor connection for Side Power thrusters available
separately through Mercury.
Compatible with current Mercury DTS inboard engines.
